Preci-Dip DIL Socket 2.54 mm Pitch Vertical 28 Way Surface Mount Turned Pin Open Frame 1A 110-87-628-41-105161

Free Delivery in India | Lowest Global Shipping Charges

Preci-Dip DIL Socket 2.54 mm Pitch Vertical 28 Way Surface Mount Turned Pin Open Frame 1A 110-87-628-41-105161

Name: Preci-Dip DIL Socket 2.54 mm Pitch Vertical 28 Way Surface Mount Turned Pin Open Frame 1A 110-87-628-41-105161
Brand: Preci-Dip
SKU: 215167
Price: 5.21 USD
Availability: InStock



Category DIL Socket Brand Preci-Dip Condition New

Specifications

Country of Origin	Switzerland
Voltage	100, 150V ac
Brand	Preci-Dip
Orientation	Vertical
Current	1A
Frame Type	Open Frame
Length	35.5mm
Depth	2.8mm
Width	17.7mm
Mount Type	Surface
Housing Material	Fibreglass Reinforced Polyethylene Terephthalate
Contact Material	Brass, Beryllium Copper Alloy
Series	110
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Pitch	2.54mm
Contact Plating	Tin, Gold
Number of Contacts	28
Pin Type	Turned
Row Width	15.24mm
Stock numbers	702-0691 , 702-2704 , 702-2701 , 702-2713 , 702-2767, 702-2779 , 702-2773 , 702-2798 and 702-2808 are without a centre bar

Key Features

This DIL socket features an open frame and vertical orientation for reliable circuit board connections.
The contact pitch is 2.54 mm with 28 contacts arranged in dual-in-line configuration.
Constructed with brass and beryllium copper alloy contacts for enhanced conductivity and durability.
The housing is made from fibreglass reinforced polyethylene terephthalate for high temperature resistance.
Rated for a voltage of 100 to 150V AC and a current capacity of 1A.
Supports solder termination and is compatible with reflow soldering including vapor phase processes.
Pin contacts are tin plated with gold flash for optimal signal integrity and corrosion resistance.
Operating temperature range spans from -55°C to 125°C, suitable for industrial electronics environments.

Product Description

Preci-Dip 110-87-628-41-105161 is a high-quality open frame DIL socket designed for electronic components requiring 2.54 mm pitch and vertical orientation with 28 contacts. It supports surface mount technology, optimized for reflow soldering and vapor phase methods with gull wing terminations providing robust mechanical strength on PCBs.

The socket contacts are made from brass and beryllium copper alloy, plated with tin and a gold flash for enhanced electrical performance and corrosion resistance. The housing uses fibreglass reinforced polyethylene terephthalate, providing excellent thermal stability and mechanical durability.

Operational voltage rating is 100 to 150V AC with a current limit of 1 ampere. Designed for use in industrial, laboratory, and manufacturing applications where reliable IC socket connections are critical.

The socket is constructed to endure harsh environmental conditions, with an operating temperature range from -55°C to 125°C. It measures 35.5 mm length, 17.7 mm width, and 2.8 mm depth, fitting a variety of PCB layouts and designs.

This socket is ideal for industrial electronics and instrumentation requiring precise, stable connections. Surface mount design allows easy integration during PCB assembly. The open frame construction facilitates testing and inspection during manufacturing.

Suitable for applications in electronics manufacturing, prototyping, and repair. Manufactured in Switzerland, guaranteeing adherence to strict quality and performance standards.

Preci-Dip DIL Sockets are recognized for their durability, precision, and ease of installation in industrial and laboratory equipment. They are a trusted choice for circuit designers and engineers working in complex electronic systems.
