Power Integrations High Side 1-Off Liner Power Switch IC 8-Pin DIP-B LNK562PN

Free Delivery in India | Lowest Global Shipping Charges

Power Integrations High Side 1-Off Liner Power Switch IC 8-Pin DIP-B LNK562PN

Name: Power Integrations High Side 1-Off Liner Power Switch IC 8-Pin DIP-B LNK562PN
Brand: Power Integrations
SKU: 213707
Price: 0.75 USD
Availability: InStock



Category Power Switch IC Brand Power Integrations Condition New

Specifications

Country of Origin	Malaysia
Brand	Power Integrations
Height	3.68mm
Length	9.83mm
Model	LNK562PN
Width	6.6mm
Mount Type	Through Hole
Number of inputs	1
Series	LNK562
Power Rating	1.9W
Maximum Operating Temperature	150°C
Package Type	DIP-B
Minimum Operating Temperature	-40°C
Operating Current	375mA
Number of outputs	5
Pin Count	8
Switch On Resistance RdsOn	88Ω

Key Features

Features low switch on resistance of 88 ohms for efficient power switching.
Supports one input and five outputs for versatile power control.
Power rating of 1.9 watts ensures reliable operation to moderate loads.
Operates under a wide temperature range from -40°C to 150°C.
Through hole mount with an 8-pin DIP-B package enables easy PCB integration.
Compact dimensions with length 9.83 mm, width 6.6 mm, and height 3.68 mm.
Incorporates hysteretic thermal shutdown for enhanced device safety.
Universal input range supports worldwide operation with auto-restart protection.

Product Description

Power Integrations LNK562PN is a high side 1-off liner power switch IC featuring an 8-pin DIP-B package designed for efficient power management in electronic circuits. It delivers a power rating of 1.9 W and incorporates advanced functions such as hysteretic thermal shutdown protection and frequency jittering to significantly reduce EMI, ensuring stable and reliable operation.

The device supports a universal input voltage range, making it suitable for worldwide power supply designs up to 3 W output without the need for multiple transformer designs. The self-biased circuit supports extremely low no-load power consumption under 150 mW, optimizing energy efficiency.

Its compact dimensions (9.83 mm length, 6.6 mm width, and 3.68 mm height) combined with a through-hole DIP-B package allow for easy mounting on printed circuit boards. The switch on resistance of 88Ω and operating current of 375 mA provide reliable performance in power switching applications requiring one input and five outputs.

The LNK562PN operates reliably within a wide temperature margin of -40°C to 150°C, making it well-suited for industrial, electronic component, and power management use cases where robust thermal management and EMI reduction are critical.

Low switch on resistance ensures efficient power transfer. Hysteretic thermal shutdown protects against overheating. Frequency jittering reduces EMI emission for compliance. Universal input allows for global application use cases.

Compact through-hole DIP-B package for easy mounting. Wide operating temperature range suits harsh environments. Self-biased circuit lowers no-load power consumption. Supports fast transient load response for stable power delivery.

Manufactured in Malaysia ensuring quality standards.

This Power Switch IC is ideal for industrial electronics, power supplies, lighting control, and other applications demanding reliable, low-power switching with thermal and EMI protections. Explore similar power management ICs on EnvMart for complementary solutions.
