Broadcom Solid State Relay Surface Mount 0.6 A Load 60 V Load 1.7 V Control ASSR-1420-002E

Broadcom ASSR-1420-002E is a high-performance Solid State Relay (SSR) designed for industrial, automation, and electrical applications requiring reliable and efficient switching. Its surface mount package allows easy integration on printed circuit boards, making it suitable for modern compact electronic assemblies.

The relay supports a maximum load current of 0.6 A and can operate safely at load voltages up to 60 V, with negative load voltage tolerance of -60 V. It is controlled by voltages between 0.8 V and 1.7 V ensuring compatibility with low voltage control signals.

Featuring an SPST (single pole single throw) contact configuration, this SSR maintains low on-state resistance of 1 ohm, reducing power loss and heat generation during switching. It operates efficiently over a wide temperature range from -40°C to 85°C, allowing deployment in varied environmental conditions.

The device measures 9.7 mm in length, 6.35 mm in width, and 3.6 mm in height, delivering a compact form factor for tight integration constraints. Its output stage employs a Photo MOSFET, which combines the benefits of optical isolation and MOSFET switching, resulting in fast response and low leakage current of 100 nA in off state.

The relay meets recognized industry standards including CSA Component Acceptance Notice 5 and UL 1577 certification, affirming its quality and reliability for industrial applications.

This Solid State Relay is ideal for use in industrial automation systems, control circuitry, signal conditioning, and electronic equipment requiring quiet, reliable switching without mechanical contacts.

Key applications include manufacturing automation, HVAC controls, instrumentation, and embedded control systems where durability and performance are critical. Rated for a maximum load current of 0.6 amperes. Designed for surface mount installation enhancing PCB integration.

Supports a maximum load voltage of 60 volts and minimum load voltage of -60 volts. Operates with control voltage ranging from 0.8 V minimum to 1.7 V maximum. Utilizes an SPST (Single Pole Single Throw) contact configuration for switching.

Low on-state resistance of 1 ohm ensures efficient operation. Wide operating temperature range from -40°C to 85°C. Compact dimensions make it suitable for space-constrained designs. Meets CSA Component Acceptance Notice 5 and UL 1577 standards for safety and compliance.

Photo MOSFET output type offers low off-state leakage current and fast switching. Explore a wide range of Solid State Relays and electronic components at EnvMart for your industrial automation and electrical control needs.
