MEAN WELL Ultra Slim Switched Mode DIN Rail Power Supply 85-370V AC/DC Input 48V DC, 2.1 A Output, 100.8 W HDR-100-48N

Free Delivery in India | Lowest Global Shipping Charges

MEAN WELL Ultra Slim Switched Mode DIN Rail Power Supply 85-370V AC/DC Input 48V DC, 2.1 A Output, 100.8 W HDR-100-48N

Name: MEAN WELL Ultra Slim Switched Mode DIN Rail Power Supply 85-370V AC/DC Input 48V DC, 2.1 A Output, 100.8 W HDR-100-48N
Brand: MEAN WELL
SKU: 212852



Category DIN Rail Power Supplies Brand MEAN WELL Condition New

Specifications

Country of Origin	China
Brand	MEAN WELL
Power	100.8W
Efficiency	90%
Height	90mm
Model	HDR-100-48N
Depth	54.5mm
Width	70mm
Series	Ultra Slim
Output Current	2.1A
Maximum Operating Temperature	70°C
Sub Type	Switched Mode
Minimum Operating Temperature	-30°C
Number of outputs	1
Maximum Input Voltage	370, 264V dc
Electrical Phase	1
Standards/Approvals	UL, TUV EN 609501, RoHS
Maximum Output Voltage	48V dc
Minimum Input Voltage	85V ac

Key Features

Compact and space-saving ultra slim design suitable for TS-35/7.5 and TS-35/15 DIN rails.
Full range input voltage capability supports 85V AC minimum and up to 370V DC maximum.
High efficiency of up to 90% reduces energy loss during operation.
Output voltage is adjustable for flexible application requirements.
Built-in plastic housing provides effective electrical hazard protection and isolation Class II compliance.
Wide operating temperature range from -30°C to 70°C to support diverse industrial environments.
Single output channel supplying DC voltage at 48V with 2.1 A output current.
Meets UL, TUV EN 60950-1, and RoHS standards and certifications.

Product Description

MEAN WELL HDR-100-48N is an ultra slim switched mode DIN rail power supply designed for industrial and electronic applications requiring reliable and compact power solutions. This module supports a wide input voltage range from 85 V AC to 370 V DC, allowing it to operate in varied supply conditions with single-phase AC/DC input configuration.

The power supply outputs a stable 48 V DC voltage at 2.1 A current, delivering a total power capacity of 100.8 W with an efficiency rating of 90%. Its narrow width of 70 mm and compact dimensions (90 mm height, 54.5 mm depth) enable effective utilization of space in control cabinets or industrial racks.

The plastic housing features a stepped shape that provides insulation and isolation Class II safety. The device can be mounted on standard TS-35/7.5 or TS-35/15 DIN rails commonly found in industrial environments. The output voltage is adjustable to allow fine-tuning for specific applications.

Operating temperature tolerance ranges from -30°C to 70°C, making it suitable for harsh operating conditions. It complies with internationally recognized safety standards including UL, TUV EN 60950-1, and RoHS directives, ensuring regulatory compliance and safety.

Compact ultra slim design for space-saving installation. Wide input voltage range supporting AC and DC sources. High efficiency up to 90% to minimize power loss. Adjustable DC output voltage for flexibility. Plastic housing with stepped design providing Class II isolation.

Mountable on industry standard DIN rails TS-35/7.5 or 15. Wide operating temperature range of -30°C to 70°C. Certified to UL, TUV EN 60950-1, and RoHS standards.

This power supply is ideal for industrial automation, manufacturing equipment, control panels, instrumentation, and electronic device power needs. The efficient design and flexibility make it an indispensable component in ensuring reliable DC power delivery in professional electrical and electronic systems.

Available from EnvMart in the Electronics & Electricals category under Power Supplies & Transformers, this MEAN WELL DIN Rail Power Supply HDR-100-48N offers a high-quality, robust solution for your industrial power requirements.
