Phoenix Contact TRIO POWER Switched Mode DIN Rail Power Supply AC/DC Input 85-275 V, 18 V DC Output, 10 A, 120 W 2903158

Category DIN Rail Power Supplies Brand PHOENIX CONTACT Condition New

Specifications

Country of Origin China
Brand Phoenix Contact
Power 120W
Efficiency 87%
Height 130mm
Model 2903158
Depth 115mm
IP Rating IP20
Width 35mm
Series TRIO POWER
Output Current 10A
Maximum Operating Temperature 70°C
Sub Type Switched Mode
Minimum Operating Temperature -25°C
Number of outputs 2
Maximum Input Voltage 275, 264V dc
Electrical Phase 1
Maximum Output Voltage 18V dc
Minimum Input Voltage 85V ac

Key Features

  • Supports AC/DC input voltage range of 85 to 275 V for versatile operation.
  • Compact DIN rail mounting with IP20 protection for industrial environments.
  • High efficiency of 87% ensures energy-saving performance.
  • Wide operating temperature from -25°C to +70°C for harsh conditions.
  • Offers remote DC-OK signaling for system status monitoring.
  • Mechanical robustness with vibration and shock resistance.
  • Dynamic boost capability up to 150% current for short-term overload.
  • Complies with multiple international safety and electromagnetic compatibility standards.

Product Description

Phoenix Contact 2903158 TRIO POWER Switched Mode DIN Rail Power Supply offers a compact, reliable power solution for DC-compatible industrial devices. Operating with AC or DC inputs from 85 V to 275 V, it provides a stable 18 V DC output at 10 A and 120 W power. It is engineered for durability with an IP20 rating and a broad temperature range from -25°C to 70°C, making it suitable for demanding industrial, manufacturing, and automation applications.

This power supply ensures energy efficiency with 87% efficiency and supports a remote DC-OK signal for monitoring device status. The dynamic boost feature can provide up to 150% of the nominal current for short durations, enhancing system availability during start-up or overload situations.

The device complies with an extensive list of standards including EN 61000 series for EMC, UL listings, IEC safety standards, and has been tested for vibration and shock resistance, ensuring reliable operation in challenging environments.

With compact dimensions (130 mm height, 35 mm width, 115 mm depth), the unit fits neatly into standard DIN rail assemblies, optimizing space utilization in control panels and electrical enclosures.

This power supply is widely used for industrial automation, control panels, renewable energy systems, and HVAC systems requiring a stable 18 V DC power source. Supports AC/DC input voltage range of 85 to 275 V. Provides stable 18 V DC output at 10 A current and 120 W power.

IP20 rated for protection against solid objects. Operating temperature range -25°C to 70°C. Remote DC-OK signal available for monitoring. High efficiency of 87% reduces energy waste. Dynamic boost up to 150% current for 5 seconds.

Compliant with EN, IEC, UL safety and EMC standards. Dimensions: 130 mm (H) x 35 mm (W) x 115 mm (D). Mean time between failures (MTBF) over 1,700,000 hours.

Choose Phoenix Contact TRIO POWER 2903158 for dependable DIN rail power supply solutions in industrial and commercial electrical setups. Explore additional power supply options and components on EnvMart.
