Mean Well DRE Switched Mode DIN Rail Power Supply 264V AC Input 12V DC Output, 16A, 192W DRE240-12
Specifications
| Country of Origin | India |
|---|---|
| Brand | Mean Well |
| Power | 192W |
| Efficiency | 93% |
| Height | 125mm |
| Model | DRE240-12 |
| Depth | 124mm |
| IP Rating | IP20 |
| Width | 64mm |
| Series | DRE |
| Output Current | 16A |
| Maximum Operating Temperature | 71°C |
| Sub Type | Switched Mode |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 1 |
| Maximum Input Voltage | 264V ac |
| Electrical Phase | 1 |
| Maximum Output Voltage | 12V dc |
| Minimum Input Voltage | 88V ac |
Key Features
- Universal AC input voltage ranging from 88V to 264V ensures flexibility.
- High efficiency of 93% for energy-saving operation.
- Compact DIN rail mount design with dimensions 125mm height, 64mm width, and 124mm depth.
- Operating temperature range from -40°C to 71°C suitable for harsh environments.
- Built-in active PFC and internal input filter enhance performance and reliability.
- 150% peak load capability supports temporary overload conditions.
- Parallel operation is possible using switch selectable function.
- Short circuit protection ensures device safety during faults.
Product Description
Chinfa DRE240-12 is a switched mode DIN rail power supply designed for industrial and automation applications requiring stable DC 12V output with 16A current capacity and total power of 192W. It accepts universal AC input voltage from 88V up to 264V AC, making it versatile for various power environments.
Featuring high efficiency of 93%, the power supply reduces energy losses. Its compact design with height 125mm, width 64mm, and depth 124mm allows easy installation on standard DIN rails. The device operates reliably in a wide temperature range from -40°C to 71°C.
The DRE series integrates active power factor correction (PFC) and an internal input filter to improve power quality. It supports 150% peak load capability for short bursts of increased load. A parallel function is switch selectable for extending current capacity by connecting multiple units.
Robust protections include short circuit safeguard to prevent damage under fault conditions. The power supply complies with international safety and electromagnetic compatibility standards such as UL 62368-1, UL 508, EN 55032, and EN 61558 parts 1 and 2-16, ensuring dependable and safe operation in industrial environments.
Typical applications include factory automation, industrial control systems, instrumentation, and electromagnetic drives where stable and efficient DC 12V power is required. Universal input voltage range from 88V to 264V AC for wide compatibility.
High efficiency to reduce operational costs and heat generation. Compact DIN rail mounting for easy integration in control panels. Wide operating temperature supports challenging industrial conditions. Active PFC and input filtering for stable and clean power output.
Peak load handling up to 150% enhances reliability during transient demands. Short circuit protection for enhanced electrical safety. Parallel function capability to increase output current as needed. Compliance with multiple international safety and EMC standards.
Explore a comprehensive selection of DIN Rail Power Supplies and industrial power solutions on EnvMart for reliable automation and control system implementations.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model provides an output current of 16A.
The maximum power output is 192W.
It has a high efficiency rating of 93%.
The dimensions are 125mm in height, 64mm in width, and 124mm in depth.
It operates reliably in a temperature range from -40°C to 71°C.
Yes, it supports parallel operation with a switch selectable function to extend current capacity.
It includes short circuit protection to enhance safety during faults.
The IP rating is IP20, indicating protection against solid objects but no protection against water.
It is suitable for factory automation, industrial control systems, instrumentation, and electromagnetic drives.
It complies with international safety and electromagnetic compatibility standards such as UL 62368-1, UL 508, EN 55032, and EN 61558 parts 1 and 2-16.
The maximum output voltage is 12V DC.
