MEAN WELL IP65 Encapsulated 1 Output LED Driver, 48V, 75W, 450mA DALI Dimming

Free Delivery in India | Lowest Global Shipping Charges

MEAN WELL IP65 Encapsulated 1 Output LED Driver, 48V, 75W, 450mA DALI Dimming

Name: MEAN WELL IP65 Encapsulated 1 Output LED Driver, 48V, 75W, 450mA DALI Dimming
Brand: MEAN WELL
SKU: 182558



Category LED Drivers Brand MEAN WELL Condition New

Specifications

Country of Origin	India
Brand	MEAN WELL
Model	IP65
IP Rating	IP65
Mount Type	Screw
Series	ELG-75
Configuration	Encapsulated
Sub Type	LED Driver
Operating Modes	Constant Current/Constant Voltage
Number of outputs	1
Terminal type	Wire
Maximum Output Power	75W
Input Voltage	180, 305, 254, 431V ac
Output Voltage	48V
Power Dissipation	75.8W
Standards/Approvals	CB, CE, EAC, UL, ENEC, SELV
Dimming Operation	DALI
Primary Type	AC-DC, DC-DC
Driver Current	450mA

Key Features

Features a fan-less design for high efficiency up to 91 percent.
Operating voltage input range includes 180, 254, 305, and 431 volts AC.
Designed with robust full metal housing and rated IP65 for water and dust resistance.
Supports both constant current and constant voltage operating modes.
Includes screw mount type and wire terminal connections.
Complies with CB, CE, EAC, UL, ENEC, and SELV safety standards.
Typical applications include LED street lighting, architectural lighting, bay and floodlighting.
Single output channel with 450mA driver current and DALI dimming control.

Product Description

MEAN WELL ELG-75-48DA is an IP65 rated encapsulated LED driver designed with a fan-less construction, providing 75 watts output power at 48 volts and 450mA constant current. It supports DALI dimming for precise lighting control and operates with an AC input voltage range encompassing 180 to 431 volts.

Constructed in a robust full metal housing with screw mounting and wire terminal connections, this LED driver is highly efficient with a rating up to 91 percent and suitable for use in harsh environments requiring IP65 ingress protection.

The ELG-75-48DA supports both constant current and constant voltage modes, making it optimal for a wide range of LED lighting applications such as street lighting, architectural illumination, bay lighting, and floodlighting. It complies with international safety and approval standards including CB, CE, EAC, UL, ENEC, and SELV.

The driver incorporates effective power dissipation and supports flexible dimming options via potentiometer and PWM signals, enhancing flexibility for LED system designers. Fan-less design ensures quiet operation and increased reliability.

Wide operating temperature range suitable for industrial and commercial use. Robust encapsulated design for protection against environmental factors. Single output channel with stable 450mA driver current. DALI dimming operation allows easy integration with lighting control systems.

IP65 rating guarantees resistance to dust and water ingress. Approved to multiple international standards ensuring quality and safety. Ideal for LED street lighting, architectural, bay, and floodlighting applications.

MEAN WELL’s ELG series LED Drivers are trusted in industrial and commercial lighting projects where reliability and efficiency are crucial. This IP65 rated model combines durability with sophisticated dimming and power output to meet diverse LED lighting requirements.
