HARWIN M22 Series Right Angle Through Hole Pin Header, 4 Contacts, 2 mm Pitch, 1 Row, Unshrouded M22-2030405

HARWIN M22-2030405 Right Angle Through Hole Pin Header is a 4-contact, 2 mm pitch, single-row connector designed for board-to-board interfacing in electronic assemblies. The pin header's housing is made of high temperature nylon thermoplastic that endures common solder reflow processes without degradation.

The phosphor bronze contacts are gold-plated to ensure superior conductivity and corrosion resistance. Its unshrouded design allows flexible PCB layout adaptations, while the right angle orientation supports streamlined cable routing and assembly.

This connector supports a continuous current rating of 1 ampere and operates reliably between -40°C and 105°C, making it suitable for demanding industrial and consumer electronics environments. The through-hole mount provides a robust mechanical lock to the PCB, enhancing durability during handling and operation.

The pin's tail length is 3 mm and the mating pin length is 3.5 mm, compatible with the M22 series sockets and jumpers. The design includes castellations in the housing, allowing sections to be cut to custom sizes - with care to avoid damaging the tails.

Applications for this connector include embedded PC systems, communications equipment, industrial controls, personal computing devices, and other areas requiring secure and reliable PCB connections.

Constructed with nylon housing suitable for high temperature applications. Features gold-plated phosphor bronze contacts ensuring excellent conductivity. Right angle orientation and unshrouded design for versatile PCB layouts.

Supports a current rating of 1 ampere for typical electronic uses. Pin header has 3 mm tail pin length and mates with 3.5 mm pin length connectors. Designed for through-hole mounting providing robust mechanical strength.

Operating temperature range from -40°C to 105°C suits harsh environments. Compatible with M22 series sockets, housings, and jumpers for modular system design. Ideal for use in embedded PCs, motherboards, and large electronic systems.
