HARWIN M20 Series Straight Surface Pin Header, 10 Contacts, 2 Rows, 2.54 mm Pitch, Unshrouded M20-8760542

HARWIN M20-8760542 is a straight surface mount pin header designed for printed circuit board (PCB) connection applications. Featuring 10 male contacts arranged in 2 rows with a 2.54 mm pitch, this unshrouded header provides reliable and configurable interconnection options suitable for embedded PCs, motherboards, and large electronic systems. The nylon housing allows for high temperature resistance making it compatible with reflow soldering processes.

The contact material is brass with gold plating ensuring excellent electrical conductivity and durability. This header supports a current rating of 3A and voltage of up to 250V, enabling it to serve various electronic applications including consumer electronics, communications, drives, controls, and industrial monitoring.

The operating temperature ranges from -40°C to 105°C, making it suitable for harsh environmental conditions. Its surface mount design supports board-to-board and wire-to-board configurations, facilitating versatile electrical connections. The mating pin length is 5.8 mm to ensure secure and consistent mating with corresponding M20 series PCB sockets, socket housings, and jumpers.

The header's unshrouded construction allows ease of cutting to size if needed, though care is advised regarding contact tails. Made in Taiwan, Province Of China, this component complies with industry quality expectations but has no specific standards or approvals listed.

Provides 10 male contacts arranged in 2 rows for versatile circuit connections. Pitch measures 2.54 mm ensuring standard compatibility with PCB layouts. Constructed with nylon housing suitable for high temperature reflow soldering.

Brass contacts plated in gold offer excellent conductivity and corrosion resistance. Designed for surface mount installation offering board-to-board and wire-to-board connector systems. Supports a current rating of 3A and voltage rating of 250V for robust performance.

Minimum operating temperature is -40°C and maximum operating temperature is 105°C. Unshrouded design allows straightforward mating with compatible sockets and jumpers. Manufactured in Taiwan, Province Of China adhering to quality standards.

Mating pin length of 5.8 mm facilitates secure electrical contact.

This header is widely used in industrial, communication, and consumer electronics applications for reliable and flexible PCB interconnections. Explore more high-quality connector solutions in the PCB Headers category on EnvMart.
