HARWIN Right Angle Through Hole PCB Socket 20-Contact 2 Row 1.27 mm Pitch M50-3201045

Free Delivery in India | Lowest Global Shipping Charges

HARWIN Right Angle Through Hole PCB Socket 20-Contact 2 Row 1.27 mm Pitch M50-3201045

Name: HARWIN Right Angle Through Hole PCB Socket 20-Contact 2 Row 1.27 mm Pitch M50-3201045
Brand: HARWIN
SKU: 210391
Price: 3.06 USD
Availability: InStock



Category PCB Sockets Brand HARWIN Condition New

Specifications

Country of Origin	Taiwan
Voltage	1kV
Brand	HARWIN
Orientation	Right Angle
Current	12A
Model	M50-3201045
Mount Type	Through Hole
Housing Material	Nylon
Contact Material	Brass
Series	M50
Termination Type	Solder
Maximum Operating Temperature	105°C
Sub Type	Socket Strip
Minimum Operating Temperature	-40°C
Number of Rows	2
Pitch	1.27mm
Contact Plating	Gold
Number of Contacts	20
Contact Gender	Female
Connector System	Board-to-Board

Key Features

Constructed with nylon housing ensuring durability and insulation.
Brass contacts plated with gold for superior conductivity and corrosion resistance.
Supports operating temperatures from -40 degrees Celsius to 105 degrees Celsius.
Rated for voltage up to 1 kV and current of 12 amperes.
Designed for through-hole mounting with right-angle orientation.
Solder termination type enables secure and stable installation.
Compatible with M50 series headers for seamless system integration.
Suitable for PCB applications requiring shrouded socket and pin headers.

Product Description

The HARWIN M50-3201045 Right Angle Through Hole PCB Socket is a high-quality connector designed specifically for board-to-board applications where reliability and durability are essential. Featuring 20 female contacts arranged in 2 rows, the socket uses a 1.27 mm pitch to provide compact but robust connections.

The housing material is nylon which combines excellent electrical insulation with mechanical strength. Brass contact material plated with gold ensures excellent conductivity and resistance against oxidation, supporting long-term reliable electrical performance.

This socket is rated to handle currents up to 12 amperes and voltages up to 1 kV, making it suitable for various electronic uses including industrial, communication, and computing equipment. It sustains operating temperatures from -40°C to 105°C, ensuring performance in harsh environments.

Designed for through-hole mounting, it features solder termination with a right-angle orientation, facilitating compact PCB layouts and efficient circuit board design. The socket is part of the M50 series and mates with corresponding M50 headers, enabling modular connector solutions.

Typical applications include electronic components manufacture, industrial controls, embedded system boards, and any facility requiring secure and reliable PCB socket connectors. Its shrouded design provides additional protection for pins during handling and assembly.

Durable nylon housing for electrical insulation and mechanical protection. Gold-plated brass contacts for excellent conductivity and corrosion resistance. High current and voltage ratings suitable for demanding electronic circuits.

Wide operating temperature range for versatile environmental suitability. Right angle soldered mount for optimal PCB space utilization. Compatible with M50 series connectors for versatile system design. Shrouded socket design for enhanced durability and protection.

Explore more PCB Sockets and components at EnvMart for professional-grade electronics assembly solutions.
