TE Connectivity 5-Way IDC Connector Female 1 Row 2.54mm Pitch 3A 267V AMPMODU MTE 5-103959-4

TE Connectivity 5-103959-4 IDC Connector Female 5-Way, 1 Row, 2.54 mm pitch is an AMPMODU MTE series connector designed for cable mounting in electronic and industrial applications. It supports a current of 3A and voltage rating of 267V, ensuring reliable electrical performance in demanding environments.

This connector features insulation displacement contacts (IDC) which are pre-loaded into the housing, enabling fast, one-step assembly without the need for wire stripping, thus improving production efficiency.

The connector includes a latch mechanism to maintain secure mating and polarization features integrated into the thermoplastic housing to prevent incorrect connections, enhancing system reliability.

Manufactured from phosphor bronze contacts plated with tin over nickel and housed in robust thermoplastic, it offers mechanical and corrosion resistance suitable for industrial, laboratory, manufacturing, commercial, and telecommunications uses.

The connector is designed for use with wire gauges ranging typically from 26 AWG to 22 AWG, supporting mass termination for computers, telecommunication equipment, commercial printers, test instrumentation, medical devices, and automotive controls.

The connector is pre-loaded with insulation displacement contacts for efficient assembly. Features a latch mechanism to ensure secure connection to the mating connector. Polarization features prevent mismating in applications.

Constructed with phosphor bronze contacts plated with tin over nickel for reliability. Housing is made of durable thermoplastic material for robust performance. Supports current rating of 3A and withstands voltages up to 267V.

Operates in temperature range from -65°C to 105°C suitable for various industrial environments. Designed for wire to wire and wire to board electronic equipment termination. Applications include computers, telecommunications, printers, medical equipment, and automotive controls.

Explore more connectors and IDC products from TE Connectivity on EnvMart for reliable electronic component solutions.
