ASSMANN WSW 16-Way IDC Connector Male for Cable 2 Row AWLP 16/3,2-T

Free Delivery in India | Lowest Global Shipping Charges

ASSMANN WSW 16-Way IDC Connector Male for Cable 2 Row AWLP 16/3,2-T

Name: ASSMANN WSW 16-Way IDC Connector Male for Cable 2 Row AWLP 16/3,2-T
Brand: ASSMANN WSW
SKU: 208327
Price: 0.95 USD
Availability: InStock



Category IDC Connector Brand ASSMANN WSW Condition New

Specifications

Country of Origin	China
Voltage	250V ac
Brand	ASSMANN WSW
Orientation	Straight
Current	3A
Model	AWLP 16/3,2-T
Mount Type	Cable
Housing Material	Polybutylene Terephthalate
Contact Material	Brass
Series	AWLP
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-40°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Nickel, Tin
Number of Contacts	16
Contact Gender	Male
Connector Gender	Male
Shrouded/Unshrouded	Unshrouded

Key Features

Features a 2.54mm pitch for reliable electrical connections.
Rated for 3A current and 250 V AC voltage operation.
Nickel and tin plating on brass contacts enhances durability and conductivity.
Constructed from polybutylene terephthalate housing for mechanical stability.
Operating temperature ranges from -40°C to 105°C for versatile applications.
Solder termination ensures secure cable attachment.
Connector orientation is straight to match cable routing requirements.
Male connector gender designed for mating with compatible IDC connectors.

Product Description

ASSMANN WSW AWLP 16/3,2-T is a 16-way IDC connector designed for cable mounting, featuring two rows of contacts. This male, straight orientation connector is unshrouded and suitable for wire-to-board applications where reliable and robust connections are essential.

Its 2.54mm pitch and 3A current rating make it ideal for low-power industrial, electronic, and communication equipment. The brass contacts plated with nickel and tin offer excellent conductivity and resistance to corrosion, ensuring dependable electrical performance in harsh environments.

The housing is composed of polybutylene terephthalate, providing mechanical strength, chemical resistance, and thermal stability within the operating temperature range of -40°C to 105°C. Solder termination type facilitates firm cable attachment for durable use.

This connector is part of the AWLP series from ASSMANN WSW, recognized for quality and compatibility in electronic components. It is unshrouded to allow flexible cable routing and mating with corresponding IDC components in assembly lines, manufacturing equipment, and laboratory electronics.

Features a 2.54mm pitch for reliable electrical connections. Rated for 3A current and 250 V AC voltage operation. Nickel and tin plating on brass contacts enhances durability and conductivity. Constructed from polybutylene terephthalate housing for mechanical stability.

Operating temperature ranges from -40°C to 105°C for versatile applications. Solder termination ensures secure cable attachment. Connector orientation is straight to match cable routing requirements. Male connector gender designed for mating with compatible IDC connectors.

Complies with AWLP series standards for interchangeability. Manufactured in China under ASSMANN WSW brand.

This ASSMANN WSW IDC connector is widely used in electronics manufacturing, automation controls, industrial machinery, telecommunications, and laboratory instrumentation where high-quality cable connections are critical.
