ASSMANN WSW 16-Way IDC Connector Male for Cable 2 Row, 250V AC, 1A Current, Shrouded, Tin Nickel Gold Plating AWHC 16-0111-T

Free Delivery in India | Lowest Global Shipping Charges

ASSMANN WSW 16-Way IDC Connector Male for Cable 2 Row, 250V AC, 1A Current, Shrouded, Tin Nickel Gold Plating AWHC 16-0111-T

Name: ASSMANN WSW 16-Way IDC Connector Male for Cable 2 Row, 250V AC, 1A Current, Shrouded, Tin Nickel Gold Plating AWHC 16-0111-T
Brand: ASSMANN WSW
SKU: 208298
Price: 2.92 USD
Availability: InStock



Category IDC Connector Brand ASSMANN WSW Condition New

Specifications

Country of Origin	China
Voltage	250V ac
Brand	ASSMANN WSW
Orientation	Right Angle
Current	1A
Model	AWHC 16-0111-T
Mount Type	Cable
Housing Material	Polybutylene Terephthalate
Contact Material	Brass
Series	AWHC
Termination Type	IDC
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-40°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Tin, Nickel, Gold
Number of Contacts	16
Contact Gender	Male
Connector Gender	Male
Shrouded/Unshrouded	Shrouded

Key Features

Features a 16-contact, 2-row configuration suitable for compact cable assemblies.
Operates at a voltage rating of 250V AC and supports a current of up to 1 ampere.
Manufactured with brass contacts plated in tin, nickel, and gold for enhanced conductivity and corrosion resistance.
Housing is made of durable polybutylene terephthalate, providing mechanical strength and thermal stability.
Right-angle cable mount orientation permits efficient space utilization in assemblies.
Minimum operating temperature of -40°C and maximum of 105°C ensures reliable performance across a wide temperature range.
Termination by insulation displacement contact (IDC) method enables quick and solderless installation.
Contact pitch is 2.54 mm, standard for many PCB and cable applications.

Product Description

ASSMANN WSW AWHC 16-0111-T is a high-quality 16-way IDC male connector designed for cable applications, featuring a 2-row configuration and a standard 2.54 mm pitch. It supports an operating voltage of 250V AC and a current of 1A, making it suitable for various industrial, electronic components, communication, and automation systems.

The connector utilizes brass contacts with tin, nickel, and gold plating to ensure optimal electrical conductivity and corrosion resistance. The housing is molded from polybutylene terephthalate, offering excellent mechanical durability and stability under thermal stress.

Its right-angle cable mounting and shrouded design provide effective space saving and pin protection, reducing the risk of damage during assembly or operation. The termination type is insulation displacement contact (IDC), allowing quick, solderless cable connection which improves production efficiency and reliability.

This connector is engineered to operate reliably in harsh environments, with a temperature range from -40°C to 105°C. It is ideal for use in industrial automation, electronic device manufacturing, power connectors, and other wiring harness configurations. This product is manufactured in China and does not have specific certifications listed.

Features a 16-contact, 2-row cable IDC connector configuration. Contact pitch of 2.54 mm for compatibility with standard PCBs and cables. Supports 250V AC voltage and 1A current rating. Brass contact material with tin, nickel, and gold plating for durability.

Polybutylene terephthalate housing for mechanical and thermal stability. Right-angle orientation for efficient cable routing. Operating temperature range: -40°C to 105°C. Shrouded connector design for pin protection. IDC termination type enables solderless cable connections.

Manufactured in China.

This ASSMANN WSW IDC Connector series improves productivity and reliability in cable assembly applications. Explore more industrial electronic connectors and components on EnvMart's Electronics & Electricals category.
