ASSMANN WSW 60-Way IDC Connector Female Cable Mount, 2 Row, 250V AC, 1A, Gold over Nickel Plating AWP 60-7240-T
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 250V ac |
| Brand | ASSMANN WSW |
| Orientation | Right Angle |
| Current | 1A |
| Model | AWP 60-7240-T |
| Mount Type | Cable |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Brass |
| Series | AWP |
| Termination Type | IDC |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold over Nickel |
| Number of Contacts | 60 |
| Contact Gender | Female |
| Connector Gender | Female |
| Shrouded/Unshrouded | Shrouded |
Key Features
- Supports 60 contacts arranged in 2 rows for ribbon cable connectivity.
- Rated for 250V AC voltage and 1A current capacity.
- Construction includes gold over nickel plated brass contacts for durability.
- Housing is made with Polybutylene Terephthalate (PBT) material providing UL94V-0 flame resistance.
- Designed with right angle orientation and shrouded female contacts.
- Suitable for operating temperatures from -55°C to 105°C.
- Termination type is Insulation Displacement Contact (IDC) for efficient cable assembly.
- Central polarization ensures correct mating and reliable connection.
Product Description
The ASSMANN WSW AWP 60-7240-T is a 60-way IDC connector designed for female cable mounting, featuring a robust double row layout with a 2.54mm pitch between contacts. It integrates gold over nickel plated brass contacts within a highly durable Polybutylene Terephthalate (PBT) housing, offering superior electrical performance and mechanical reliability.
This cable connector supports a voltage rating of 250V AC and a maximum current of 1A, compliant with industrial standards, suitable for demanding operating environments ranging from -55°C to 105°C. The connector's right angle orientation and shrouded female contacts ensure secure mating and mechanical protection.
Termination is achieved via IDC (Insulation Displacement Contact) technology, facilitating efficient ribbon cable assembly with central polarization to guarantee correct installation and connection integrity.
This product is widely used across electronics manufacturing, industrial automation, power distribution, and other commercial applications requiring reliable cable-to-board connections.
Package includes a single ASSMANN WSW 60-way female IDC Connector suitable for cable mounting, engineered for high-quality industrial and electronic applications. Supports 60 contacts arranged in 2 rows for ribbon cable connectivity.
Rated for 250V AC voltage and 1A current capacity. Construction includes gold over nickel plated brass contacts for durability. Housing is made with Polybutylene Terephthalate (PBT) material providing UL94V-0 flame resistance.
Designed with right angle orientation and shrouded female contacts. Suitable for operating temperatures from -55°C to 105°C. Termination type is Insulation Displacement Contact (IDC) for efficient cable assembly. Central polarization ensures correct mating and reliable connection.
Ideal for electronics, power, and industrial automation applications. Manufactured in China with new product condition. Discover more products within the Electronics Components category on EnvMart for your electronics and industrial automation needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This connector is rated for 250V AC voltage and a maximum current capacity of 1A.
It is suitable for operating temperatures ranging from -55°C to 105°C.
The termination type for this connector is Insulation Displacement Contact (IDC), which facilitates efficient cable assembly.
The housing is constructed from Polybutylene Terephthalate (PBT), which provides UL94V-0 flame resistance.
This model supports 60 contacts arranged in 2 rows.
The connector is designed with a right angle orientation.
The contacts are made of brass and feature gold over nickel plating for enhanced durability.
The pitch between the contacts is 2.54mm.
Yes, it is widely used in electronics manufacturing, industrial automation, and power distribution applications.
The connector gender is female, and it is designed for female cable mounting.
This connector is manufactured in China.
Yes, this model features shrouded female contacts for secure mating and mechanical protection.
