Molex Mini-Fit Jr Series Straight Through Hole PCB Header 6 Contacts 4.2 mm Pitch 2 Row Shrouded 39-29-9062

Molex 39-29-9062 Mini-Fit Jr Series Straight Through Hole PCB Header features a 4.2 mm pitch, 6 male contacts arranged in 2 rows, housed in a shrouded nylon body. Designed to handle currents up to 9A per circuit, it ensures reliability in demanding electrical applications. It is suited for wire-to-board connections and offers secure mounting through PCB through-hole soldering.

This connector series provides fully isolated terminals to protect against debris and arcing, while the scoop-proof housing prevents damage to contact pins during angled mating. The polarization and keying features eliminate the risk of misalignment or mismating, enhancing reliability during assembly and operation.

A positive locking mechanism with an audible click signal guarantees a secure connection and prevents accidental disconnections caused by shock or vibration. The connector body is engineered with materials compliant with UL flame retardancy standards (UL94V-0 or UL94V-2). Contact material is brass plated with tin, combining excellent electrical conductivity and resistance to corrosion.

The operational temperature range of -40°C to 105°C makes it suitable for a wide variety of environments including industrial automation, consumer appliances, networking equipment, and more. Versions featuring PCB retention pegs and mounting flanges add flexibility in mounting options.

These Mini-Fit Junior header connectors are ideal for power, high-density wire-to-wire and wire-to-board applications requiring design adaptability and superior performance. Up to 9A current capacity per circuit. Fully isolated terminals for enhanced safety and performance.

Scoop-proof housings prevent pin damage during mating. Polarization and keying to avoid misalignment errors. Secure positive locking with audible mating confirmation. Through-hole mount with solder termination ensures durable PCB connections.

Brass contacts with tin plating provide reliable conductivity. Wide temperature range operation (-40°C to 105°C). Shrouded design for protection against environmental factors. Manufactured in Mexico to high quality standards.
