Wurth Elektronik WE-TPC 1028 Shielded Wirewound Surface Mount Inductor with Ferrite Core 4.7μH ±30% 4.6A 7440650047
Specifications
| Country of Origin | India |
|---|---|
| Brand | Wurth Elektronik |
| Operating Temperature | - 40 to +125°C |
| Height | 2.8mm |
| Length | 10mm |
| Depth | 10mm |
| Packaging | Tape & Reel |
| Series | WE-TPC |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 4.7μH |
| Package/Case | 1028 |
| Maximum DC Current | 4.6A |
| Maximum DC Resistance | 23mΩ |
| Inductance Tolerance | ±30 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 40MHz |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
| Standards/ApprovalsIEC 60286-3 | 2013, IEC 61249-2-21, IPC/JEDEC J-STD-020E, JEDEC JS709B, REACH, RoHS |
| IEC 60286-3 | 2013, IEC 61249-2-21, IPC/JEDEC J-STD-020E, JEDEC JS709B, REACH, RoHS |
Key Features
- Features a ferrite core for efficient magnetic shielding and low leakage field.
- Compact 1028 package size with 10mm length, 2.8mm height, and 10mm depth.
- Inductor construction is wirewound ensuring robust performance.
- Operating temperature range from -40°C to 125°C for versatile applications.
- IEC 60286-3 and other industry standard compliant ensuring reliability.
- Maximum DC resistance of 23 milliohms minimizes power loss.
- Supplied in tape and reel packaging for automated assembly.
- Designed for surface mount termination style for PCB mounting.
Product Description
Wurth Elektronik 7440650047 WE-TPC 1028 shielded wirewound surface mount inductor is designed with a ferrite core and offers a nominal inductance of 4.7μH ±30% tolerance. It has a high current carrying capacity of 4.6 A DC, making it ideal for compact electronic equipment requiring efficient power inductors.
The inductor features a magnetic shield that reduces leakage fields and improves performance in sensitive electronic circuits. Its 1028 package form factor (10mm length, 2.8mm height, and 10mm depth) makes it suitable for high-density PCB layouts.
Constructed with wirewound technology, it ensures stable inductance and low DC resistance of 23mΩ, contributing to energy efficiency in applications. It complies with automotive standard AEC-Q200 and other key certifications like IEC 60286-3, IPC/JEDEC J-STD-020E, and REACH, making it fit for automotive and industrial uses.
Operating reliably across a wide temperature range of -40°C to 125°C, this inductor is suited for portable power devices (PDAs, digital cameras), DC/DC converters, embedded PCs, and telemetric data gathering. The product ships in tape and reel packaging, facilitating surface mount technology assembly lines.
Features a ferrite core providing magnetic shielding to reduce electromagnetic interference. Compact 1028 surface mount package for space-saving PCB design. Capable of sustaining up to 4.6 A DC current with low internal resistance.
Wide operating temperature range from -40°C to 125°C for harsh environments. Meets automotive-grade and international quality standards for dependable use. Wirewound construction ensures reliability and consistency in inductance.
Maximum self-resonant frequency of 40 MHz supports high-frequency applications. Tape and reel packaging suitable for automated manufacturing.
This Wurth Elektronik WE-TPC series inductor is ideal for industrial, automotive, telecommunications, and consumer electronics applications requiring high performance and compact inductors. For more options, explore related Surface Mount Inductors in the EnvMart electronic components category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The nominal inductance of this model is 4.7μH with a tolerance of ±30%.
It can sustain a maximum DC current of 4.6A.
This inductor has a length of 10mm, a height of 2.8mm, and a depth of 10mm.
The operating temperature range is from -40°C to +125°C.
It features a wirewound construction, which ensures stable inductance and low DC resistance.
The maximum DC resistance is 23 milliohms, which helps minimize power loss.
The maximum self-resonant frequency is 40 MHz, making it suitable for high-frequency applications.
It is supplied in tape and reel packaging, which is suitable for automated assembly.
This inductor complies with the automotive standard AEC-Q200.
It meets several standards including IEC 60286-3, IPC/JEDEC J-STD-020E, and REACH.
The termination style is surface mount, designed for PCB mounting.
It is suitable for applications in portable power devices, DC/DC converters, and telemetric data gathering.
