Wurth Elektronik WE-TPC 2813 Shielded Wirewound Surface Mount Inductor with Ferrite Core 1μH ±30% 2.5A 744029001

Wurth Elektronik 744029001 WE-TPC series shielded wirewound surface mount inductor features a ferrite core with an inductance of 1μH ±30% and a maximum DC current rating of 2.5 A. Encased in a compact 2813 package, this inductor measures 2.8 mm in length, 2.78 mm in diameter, and 1.35 mm in height. It exhibits a low maximum DC resistance of 55 mΩ and a maximum self-resonant frequency of 150 MHz, ensuring effective performance in high-frequency circuits.

The inductor is magnetically shielded to reduce electromagnetic interference and leakage fields, making it ideal for sensitive electronics. It operates within a wide temperature range from -40°C to 125°C, suitable for demanding environmental conditions.

This wirewound construction offers enhanced inductance stability and current handling, perfect for portable power devices such as PDAs, digital cameras, PCMCIA cards, and displays. It is extensively used in DC/DC converters, embedded PCs, and mobile data gathering or telemetry systems.

The WE-TPC series complies with international standards including IEC 60286-3:2013, IEC 61249-2-21, IPC/JEDEC J-STD-020E, JEDEC JS709B, REACH, and RoHS, ensuring high-quality and environmentally compliant components.

Manufactured in China, this product is packaged in tape and reel format for ease of automated assembly. Features a ferrite core for efficient magnetic shielding. Supports a maximum DC current of 2.5 A for reliable power handling.

Compact 2813 package with dimensions 2.8 mm length, 2.78 mm diameter, and 1.35 mm height. Maximum DC resistance of 55 mΩ ensuring low power losses. Operates reliably between -40°C and 125°C operating temperature range. Magnetically shielded to reduce leakage fields and EMI interference.

Wirewound construction providing high inductance stability. Suitable for portable power, DC/DC converters, embedded PC, and mobile telemetry applications. Explore the extensive range of Surface Mount Inductors and other electronic components on EnvMart for reliable industrial and commercial applications.
