MEAN WELL 1W Surface Mount Switching Power Supply 15V DC 67mA IRM-01-15S

Free Delivery in India | Lowest Global Shipping Charges

MEAN WELL 1W Surface Mount Switching Power Supply 15V DC 67mA IRM-01-15S

Name: MEAN WELL 1W Surface Mount Switching Power Supply 15V DC 67mA IRM-01-15S
Brand: MEAN WELL
SKU: 204301



Category Switching Power Supplies Brand MEAN WELL Condition New

Specifications

Country of Origin	India
Brand	MEAN WELL
Power	1W
Efficiency	75%
Length	33.7mm
Model	IRM-01-15S
Depth	16mm
Gross Weight	19g
Width	22.2mm
Mount Type	Surface
EMC Immunity	Compliance to EN61000-4-2, 3, 4, 5, 6, 8, 11, EN55024, heavy industry level (surge L-N: 1 K V), criteria A
Series	IRM
Maximum Operating Temperature	85°C
Minimum Operating Temperature	-30°C
Number of outputs	1
Maximum Input Voltage	430, 305V dc
Maximum Output Voltage	15V dc
SMPS Output Current	67mA
Minimum Input Voltage	85V ac
EMC Emission	Compliance to EN55022 (CISPR22) Class B, EN61000-3-2,-3

Key Features

Compact surface mount design suitable for PCB integration.
Universal input voltage range from 85V AC to 305V AC.
High efficiency up to 77% with low no-load power consumption.
Built-in protections for overvoltage, overload, and short circuit.
Operating temperature range suitable for industrial applications from -30°C to 85°C.
Constructed with a phenolic case and fully potted silicone for environmental resistance.
Meets global safety standards including UL, TUV, and IEC certifications.
Provides excellent EMI filtering and EMC compliance for interference prevention.

Product Description

MEAN WELL IRM-01-15S is a 1 watt single output encapsulated switching power supply designed for surface mounting on PCBs. It outputs 15V DC voltage and 67mA current with a compact form factor measuring 33.7mm length, 22.2mm width, and 16mm depth.

This power supply supports a universal AC input voltage range from 85V AC to 305V AC and a maximum DC input voltage of 430V DC, making it versatile for various applications. The device features a phenolic case and is fully potted with silicone to provide anti-vibration resistance up to 5G, dust and moisture protection, and enhanced heat dissipation.

The IRM-01-15S model achieves high efficiency up to 77% depending on load, while maintaining low no-load power consumption below 0.075 watts, meeting worldwide regulations for power consumption.

Safety and electromagnetic compatibility are ensured through comprehensive certifications including UL60950-1, TUV EN60950-1, IEC60601-1 design compliance, and EMC standards EN55022 Class B and EN61000 immunity levels suitable for heavy industrial environments.

Protection features include overvoltage, overload, and short circuit safeguards, complemented by Class II insulation and operation cooled by free air convection without the need for fans.

Typical applications for the IRM-01-15S include handheld electronic devices, factory automation machinery, mechanical equipment, and industrial electrical systems requiring a reliable low-power supply.

This compact and lightweight power supply module is an ideal solution where space constraints and environmental robustness are critical. Compact surface mount design suitable for PCB integration. Universal AC input voltage of 85V to 305V.

High efficiency up to 77% with low standby consumption. Built-in protections for overvoltage, overload, and short circuit. Wide operating temperature range from -30°C to 85°C. Phenolic case with silicone potting for durability.

Compliance with global safety and EMC standards. Class II insulation and free air convection cooling. Lightweight and space-saving design at 19 grams. Explore the range of MEAN WELL Switching Power Supplies and related electronic components at EnvMart for industrial, laboratory, and commercial power solutions.
