Relpol PCB Power Relay, 12V dc Coil, 8A Switching Current, 1 CO RM96-1011-35-1012

Free Delivery in India | Lowest Global Shipping Charges

Relpol PCB Power Relay, 12V dc Coil, 8A Switching Current, 1 CO RM96-1011-35-1012

Name: Relpol PCB Power Relay, 12V dc Coil, 8A Switching Current, 1 CO RM96-1011-35-1012
Brand: Relpol
SKU: 202402
Price: 5.37 USD
Availability: InStock



Category Power Relay Brand Relpol Condition New

Specifications

Country of Origin	Poland
Brand	Relpol
Height	16.2mm
Length	30mm
Model	RM96-1011-35-1012
Width	10mm
Mount Type	PCB
Contact Material	Silver Alloy
Series	RM96
Maximum Operating Temperature	80°C
Contact Configuration	1 CO
Minimum Operating Temperature	-40°C
Switching Current	8A
Terminal type	PCB Pin
Contact Resistance	100mΩ
Standards/Approvals	RoHS, EAC
Coil Resistance	660Ω
Coil Voltage	12V dc
Switching DC Voltage	24V dc
Switching AC Voltage	440V
Coil Power	300mW

Key Features

Designed for PCB mounting with a compact size and high shock resistance.
Coil resistance of 660 ohms provides efficient operation.
Switching power rated at 2 kVA suitable for various electrical loads.
Operates efficiently between -40°C and 80°C for durability in harsh environments.
Contact material composed of silver alloy for reliable electrical conductivity.
Complies with RoHS and EAC standards ensuring environmental and safety compliance.
Ideal for use in household appliances, automation systems, electronic instruments, and telecommunication devices.
Terminal type is PCB pin for secure and easy mounting.

Product Description

Relpol RM96-1011-35-1012 PCB Power Relay is a high-performance miniature relay designed for PCB mounting applications. It operates on a 12V DC coil voltage and supports an 8A switching current with a single changeover (1 CO) contact configuration. This relay is ideal for use in industrial, laboratory, construction, HVAC, manufacturing, and telecommunications applications where reliable power switching is essential.

The relay’s compact dimensions (30mm length, 16.2mm height, and 10mm width) and coil resistance of 660Ω ensure efficient power consumption and space-saving installation. Rated for switching voltages up to 440V AC and 24V DC with a maximum switching power of 2 kVA, the relay reliably handles a variety of electrical loads.

Designed to withstand harsh environments, the RM96 model operates effectively in temperature ranges from -40°C to 80°C. Contacts made of silver alloy reduce contact resistance to approximately 100mΩ, enhancing conductivity and longevity. The relay’s PCB pin terminal type facilitates easy and secure soldering onto printed circuit boards.

Compliant with RoHS and EAC standards, the product meets environmental and safety requirements. The relay is produced in Poland, reflecting quality manufacturing standards. Applications include general electrical appliance control, automation systems, electronic equipment, instrumentation, meters, telecommunication devices, and remote control systems.

Designed for PCB mounting with a compact size and high shock resistance. Coil resistance of 660 ohms provides efficient operation. Switching power rated at 2 kVA suitable for various electrical loads. Operates efficiently between -40°C and 80°C for durability in harsh environments.

Contact material composed of silver alloy for reliable electrical conductivity. Complies with RoHS and EAC standards ensuring environmental and safety compliance. Ideal for use in household appliances, automation systems, electronic instruments, and telecommunication devices.

Terminal type is PCB pin for secure and easy mounting. Explore more high-quality Power Relays and electrical components at EnvMart for your industrial and commercial needs.
