Panasonic PCB Power Relay, 12V DC Coil, 5A Switching Current, SPST, Gold Plated Contacts APAN3112

Panasonic APAN3112 is a PCB Power Relay with a 12V DC coil and SPST (Single Pole Single Throw) contact configuration designed for industrial and commercial equipment. It supports a switching current of 5A and a maximum switching power of 150W, making it suitable for a range of electrical control applications such as industrial machinery, office equipment, and programmable controllers.

This relay features gold plated contacts that ensure low contact resistance of 30mΩ and high reliability. Its nominal coil power is 110 mW, which helps in reducing power consumption. It operates efficiently within a temperature range from -40°C to 90°C, making it robust for harsh environments.

The relay is designed for high density PCB mounting and complies with international standards including RoHS and cULus certification. The compact size with dimensions 20mm length, 5mm width, and 12.5mm height enables integration into space-restricted assemblies. Coil resistance is 1.3kΩ ensuring stability of coil operation.

Its primary applications include use in industrial equipment, measuring devices, office automation, test equipment, and temperature controllers, providing versatile functionality in automation and control systems.

The product is manufactured in China and adheres to IEC61010 reinforced insulation standards, providing safe and reliable electrical isolation. Designed for high density mounting in electronic circuits. Operates at nominal coil power of 110 mW for low energy consumption.

Offers a maximum switching power of 150 W suitable for varied applications. Gold plated contacts provide excellent conductivity and reduced contact resistance. Complies with RoHS and cULus standards ensuring safety and quality.

Wide operating temperature range from -40°C up to 90°C for durability. Compact dimensions with length 20mm, width 5mm, and height 12.5mm for space saving. Ideal for industrial, measuring, office, and programmable controller equipment.

Manufactured in China with high insulation distance meeting IEC61010 reinforced insulation standards. For reliable and efficient power switching solutions, explore more products in the Power Relay category on EnvMart.
