Panasonic PCB Power Relay 5V dc Coil 10A Switching Current SPDT ALQ105
Specifications
| Country of Origin | Thailand |
|---|---|
| Brand | Panasonic |
| Height | 15.6mm |
| Length | 20mm |
| Model | ALQ105 |
| Width | 10mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | ALQ |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 10A |
| Terminal type | PCB Pin |
| Ambient Temperature | - 40°C to +85°C |
| Contact Resistance | 100mΩ |
| Standards/Approvals | CQC, CSA, VDE, cUL, cULus, UL |
| Coil Resistance | 62.5Ω |
| Coil Voltage | 5V dc |
| Switching DC Voltage | 30V dc |
| Switching AC Voltage | 250V |
| Coil Power | 400mW |
| High surge voltage | 8000 V |
| High breakdown voltage | 4000 V |
Key Features
- Compact PCB mount relay designed for high switching capacity applications.
- Operates reliably over a wide ambient temperature range from -40°C to 85°C.
- Features silver alloy contacts with low contact resistance of 100mΩ.
- Supports switching AC voltages up to 250V and DC voltages up to 30V.
- Coil resistance of 62.5Ω and coil power consumption of 400mW for efficient operation.
- Robust insulation and high surge voltage ratings of 8000 V ensure durability.
- Suitable for appliance, industrial, and robotics applications requiring compact, reliable relays.
Product Description
Panasonic ALQ105 is a high-performance PCB Power Relay designed for applications requiring compact size and robust switching capability. With a coil voltage of 5V dc and a switching current capacity of 10A, it delivers dependable operation for various electrical and automation uses.
This relay features a Single Pole Double Throw (SPDT) contact configuration, silver alloy contacts, and low contact resistance of 100mΩ, ensuring efficient and reliable signal switching. The coil resistance of 62.5Ω and coil power consumption of 400mW support low power consumption and effective control.
The ALQ105 relay operates over a broad ambient temperature range of -40°C to +85°C, making it suitable for demanding environments. It offers a switching AC voltage rating of 250V and DC switching up to 30V, withstanding high surge voltages up to 8000 V and breakdown voltage of 4000 V, which assures excellent insulation and durability.
Its compact dimensions (20mm length, 15.6mm height, and 10mm width) make it ideal for PCB mounting in applications like household appliances, industrial equipment, robot controls, and power supplies.
Certified by CQC, CSA, VDE, cUL, cULus, and UL standards, the Panasonic ALQ105 relay offers a balance of performance, reliability, and safety compliance for industrial and commercial electronics circuits.
Compact PCB mount relay with high switching capacity. Wide operating temperature range from -40°C to 85°C. Low contact resistance silver alloy contacts. High surge voltage of 8000 V and breakdown voltage of 4000 V. Efficient coil power consumption at 400mW.
Suitable for appliances, industrial, robotics, and power supply applications. Explore more in our Electronics & Electricals category for Relays and Contactors for diverse industrial and commercial needs at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The switching current capacity of this relay is 10A.
The coil voltage for the Panasonic ALQ105 is 5V dc.
This model has dimensions of 20mm in length, 15.6mm in height, and 10mm in width.
The relay operates over a wide ambient temperature range from -40°C to +85°C.
It features a Single Pole Double Throw (SPDT) contact configuration.
It can switch AC voltages up to 250V and DC voltages up to 30V.
The contact material is silver alloy, which provides low contact resistance.
The coil power consumption is 400mW.
The contact resistance is 100mΩ.
This relay is certified by CQC, CSA, VDE, cUL, cULus, and UL standards.
The maximum surge voltage rating is 8000 V.
It is designed for PCB mounting with PCB pin terminals.
