Panasonic Power Relay PCB Mount 24V DC Coil 10A Switching Current SPDT ALQ124
Specifications
| Country of Origin | Thailand |
|---|---|
| Brand | Panasonic |
| Height | 15.6mm |
| Length | 20mm |
| Model | ALQ124 |
| Width | 10mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | ALQ |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 10A |
| Terminal type | PCB Pin |
| Ambient Temperature | - 40°C to +85°C |
| Contact Resistance | 100mΩ |
| Standards/Approvals | VDE, RoHS |
| Coil Resistance | 1.4kΩ |
| Coil Voltage | 24V dc |
| Switching DC Voltage | 30V dc |
| Switching AC Voltage | 250V |
| Coil Power | 400mW |
| Switching Power | 150W |
| High surge voltage | 8000 V |
| High breakdown voltage | 4000 V |
Key Features
- Compact design suitable for space-constrained applications.
- Operates reliably between -40°C and +85°C ambient temperature.
- High switching capacity with 150W power rating.
- Robust silver alloy contacts ensure low 100mΩ contact resistance.
- Designed to handle high surge voltage up to 8000 V and breakdown voltage of 4000 V.
- Coil resistance of 1.4kΩ and coil power consumption of 400mW for efficient operation.
- Compliant with VDE and RoHS standards for quality assurance.
- Contact material made from silver alloy for enhanced durability.
Product Description
Panasonic ALQ124 Power Relay is a high-quality PCB-mount single-pole double-throw (SPDT) relay designed for a wide range of industrial and consumer applications. Featuring a 24V DC coil and a switching current of 10A, this compact relay can reliably switch loads up to 150W, operating within ambient temperatures from -40°C up to +85°C.
The relay's silver alloy contacts and low 100mΩ contact resistance guarantee long-term durability and efficient electrical performance. It is capable of handling high surge voltages of up to 8000 V and breakdown voltages up to 4000 V, ensuring robustness in demanding environments.
The ALQ124 series is compliance certified with VDE and RoHS standards, meeting essential safety and environmental regulations. Coil specifications include a resistance of 1.4kΩ and power consumption of 400mW, optimized for minimal energy loss.
With dimensions of 20mm length, 10mm width, and 15.6mm height, this relay is designed specifically for PCB mounting using PCB pins for secure and reliable connections. This relay is well-suited for applications such as refrigerators, cooking ovens, washing machines, air conditioners, motor control, robotics, and power supply systems.
Compact size with high switching capacity. Wide ambient temperature range from -40°C to +85°C. High surge and breakdown voltages for electrical reliability. Silver alloy contacts offer low resistance and durability. Efficient coil power of 400mW with 1.4kΩ coil resistance.
Compliant with VDE and RoHS standards. PCB mount with standard pin terminals. Designed for industrial and consumer appliance applications. Dimensions: 20mm x 10mm x 15.6mm (LxWxH). Reliable operation at 24V DC coil voltage.
Explore the Electronics & Electricals category at EnvMart for a wide range of Power Relays and related components from top brands like Panasonic.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a switching current capacity of 10A, allowing it to handle various load requirements effectively.
The coil voltage for this relay is 24V DC, which is necessary for its operation.
The relay measures 20mm in length, 10mm in width, and 15.6mm in height, making it suitable for PCB mounting.
It can operate reliably in ambient temperatures ranging from -40°C to +85°C.
This unit features a single-pole double-throw (SPDT) contact configuration, allowing for versatile switching applications.
The contact resistance is low at 100mΩ, which helps ensure efficient electrical performance.
The coil power consumption is 400mW, optimized for minimal energy loss during operation.
The relay has a breakdown voltage of 4000 V, providing robust electrical reliability in demanding environments.
Yes, it is compliant with VDE and RoHS standards, ensuring it meets essential safety and environmental regulations.
This model is designed for PCB mounting, utilizing standard PCB pin terminals for secure connections.
The maximum switching power rating is 150W, allowing it to handle substantial loads effectively.
The coil resistance is 1.4kΩ, which is a critical specification for its operation efficiency.
