Hirose DF3 Series Straight Surface PCB Header, 4 Contacts, 2 mm Pitch, 1 Row, Shrouded DF3EA-4P-2V(51)

Hirose DF3EA-4P-2V(51) is a Straight Surface PCB Header connector from the DF3 series designed with 4 male contacts, spaced at a 2 mm pitch in a single-row, shrouded configuration. It is made with a polyamide housing, brass contact material plated with gold for reliable conductivity and durability. The connector is surface mount type, ensuring low profile and space-efficient assembly onto PCBs.

This header supports a maximum current of 3 amperes and can withstand voltages up to 250 volts, operating reliably within a temperature range of -55°C to 105°C. Its friction locking mechanism ensures a secure connection with mating components, preventing accidental disconnections.

Additional mechanical features include PCB mounting bosses that provide precise positioning during soldering and reinforced metal fittings on both sides of the housing that secure the connector firmly to the PCB, minimizing stress and solder joint peeling risks.

Applications for this connector are broad within electronics and electrical industries, especially suitable for business equipment such as copy machines and printers, requiring durable, compact, and high-performance PCB connectors.

Features a friction locking mechanism for secure mating connection. Low profile design suitable for surface mount technology applications. Constructed with polyamide housing and brass contacts with gold plating. Supports 3A current and operates up to 250V with excellent temperature resistance from -55°C to 105°C.

Includes PCB mounting bosses for accurate positioning and reinforced metal fittings to prevent peeling. Ideal for business equipment including copiers and printers.

Explore our wide range of reliable PCB connectors at EnvMart for industrial, commercial, and electronic applications, ensuring you find the perfect match for your design requirements.
