Microchip MOSFET Gate Driver Dual Low-Side 1.5A 18V 8-Pin DIP MIC4426YN

Free Delivery in India | Lowest Global Shipping Charges

Microchip MOSFET Gate Driver Dual Low-Side 1.5A 18V 8-Pin DIP MIC4426YN

Name: Microchip MOSFET Gate Driver Dual Low-Side 1.5A 18V 8-Pin DIP MIC4426YN
Brand: Microchip
SKU: 153309
Price: 1.95 USD
Availability: InStock



Category MOSFET Gate Driver Brand Microchip Condition New

Specifications

Country of Origin	Thailand
Brand	Microchip
Height	3.3mm
Length	9.4mm
Model	MIC4426YN
Width	8.13mm
Mount Type	Through Hole
Series	MIC4426
Output Current	1.5A
Maximum Operating Temperature	85°C
Package Type	DIP
Minimum Operating Temperature	-40°C
Number of outputs	2
Rise Time	40ns
Pin Count	8
Minimum Supply Voltage	18V
Number of Drivers	2
Fall Time	40ns
Driver Type	MOSFET

Key Features

Operates in a voltage range of 4.5V to 18V for versatile applications.
Features dual noninverting outputs for efficient MOSFET driving.
Provides 1.5A peak output current with matched rise and fall times of 40ns.
Low quiescent current consumption with 4mA at logic 1 input.
Latch-up protection allowing over 500mA reverse current for reliability.
Compact 8-pin DIP through-hole package with dimensions 9.4mm length and 8.13mm width.
Operating temperature range from -40°C to 85°C suitable for industrial environments.
7Ω output impedance ensuring stable switching performance.

Product Description

Microchip MIC4426YN MOSFET Gate Driver is a highly reliable dual low-side driver designed on BiCMOS/DMOS process technology, ensuring low power consumption and high efficiency. This device provides precise translation of TTL or CMOS input logic levels to output voltage levels within 25mV of the positive supply or ground, outperforming conventional bipolar drivers.

The MIC4426YN offers two noninverting MOSFET outputs with a peak current capacity of 1.5A and matched rise/fall times of 40ns, enabling fast and responsive switching. Its operating voltage range spans from 4.5V to a maximum of 18V, supporting a wide array of industrial and electronic applications.

Designed for through-hole mount with a compact 8-pin DIP package, it measures 9.4mm in length, 8.13mm in width, and 3.3mm in height, suitable for varied PCB layouts. The driver includes latch-up protection capable of handling reverse currents exceeding 500mA, enhancing circuit reliability. It also delivers low quiescent currents, 4mA at logic high and 400μA at logic low inputs, optimizing energy efficiency.

The device is rated for an operating temperature range from -40°C to 85°C, making it suitable for demanding industrial environments including power management, motor control, and signal switching. It effectively switches capacitive loads of 1000pF within 25ns and features a 7Ω output impedance that ensures stable MOSFET drive signals.

This MOSFET Gate Driver from Microchip comes from Thailand and complies with basic quality expectations though it does not carry specific safety or automotive certifications. It fits seamlessly into semiconductor and power management IC applications where precise gate control and robust performance are essential.

Operates on 4.5V to 18V supply voltage ensuring versatility. Dual output drivers support two MOSFETs for efficient control. High peak output current of 1.5A supports demanding loads. Latch-up protection provides system safety and durability.

Compact 8-pin DIP through-hole package for easy PCB integration.

Industrial and electronic applications include power management systems, motor drives, and electronic switching where high reliability and speed are critical. Discover a wide selection of semiconductor components and power management ICs at EnvMart for your engineering needs.
