Texas Instruments Operational Amplifier 2.5 MHz 12V SOT-23 5-Pin LMP7701MF/NOPB
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.02mm |
| Length | 2.92mm |
| Model | LMP7701MF/NOPB |
| Width | 1.6mm |
| Mount Type | Surface |
| Series | LMP7701 |
| Output Current | 15mA |
| Maximum Operating Temperature | 125°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 1 |
| Standards/Approvals | RoHS |
| Pin Count | 5 |
| Maximum Supply Voltage | 12V |
| Minimum Supply Voltage | 3V |
| GBP - Gain Bandwidth Product | 2.5MHz |
| Input Bias Current | 400 pA |
| Slew Rate | 1V/μs |
| Input Offset Current | 40 fA |
Key Features
- This operational amplifier features a maximum supply voltage of 12V and a minimum of 3V.
- It has a low input bias current of 400 pA, enhancing precision applications.
- The device operates within a temperature range from -40°C to 125°C, suitable for harsh environments.
- It delivers an output current capability of up to 15 mA, ideal for driving loads directly.
- The amplifier's input offset voltage is low at 500 μV, improving accuracy.
- It has a slew rate of 1 V/μs, enabling adequate response speed for many analog circuits.
- Compliant with RoHS standards ensuring environmental safety.
- Single channel operational amplifier with 40 fA input offset current.
Product Description
Texas Instruments LMP7701MF/NOPB operational amplifier delivers a precise low voltage solution with a gain bandwidth product of 2.5 MHz. Packaged in a compact 5-pin SOT-23 surface mount package, it is engineered for electronics and semiconductor applications requiring high accuracy and reliability. Operating from a low minimum supply voltage of 3 volts up to a maximum of 12 volts, it supports a wide range of power supply sources while maintaining excellent performance.
Featuring an ultra-low input bias current of 400 pA and an input offset voltage of 500 μV, the amplifier ensures minimum signal distortion and high fidelity. It offers a slew rate of 1 V/μs facilitating stable and quick signal response, crucial for analog signal conditioning. The maximum output current is rated at 15 mA, enabling it to drive moderate loads without additional buffers.
Designed for robust operation, the device supports a wide operating temperature range from -40°C to 125°C, making it suitable for demanding industrial and commercial environments. Its compact dimensions of approximately 2.92 mm length, 1.6 mm width, and 1.02 mm height allow for high-density PCB layouts and efficient space utilization.
RoHS compliant, this single-channel operational amplifier is ideal in precision applications including sensor signal amplification, data acquisition systems, and laboratory instrumentation. It does not conform to automotive standards, thus primarily intended for general electronics and industrial usage.
This is a surface-mount device in a SOT-23 package. Maximum supply voltage of 12 V with minimum supply voltage of 3 V. Low input bias current of 400 pA, ensuring signal precision. Operating temperature range from -40°C to 125°C.
Slew rate of 1 V/μs suitable for moderate-speed applications. Compact size: length 2.92 mm, width 1.6 mm, height 1.02 mm. Output current rating of 15 mA supports direct load drive. Input offset current at 40 fA minimizes drift and error.
Compliant to RoHS environmental standards. Single-channel operational amplifier from the LMP7701 series. Explore more Texas Instruments Operational Amplifiers and related electronics components in the Electronics & Electricals category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of the LMP7701MF/NOPB operational amplifier is 2.5 MHz, which supports its performance in various applications requiring high accuracy.
This operational amplifier has a maximum supply voltage of 12V, allowing it to operate effectively in a variety of electronic circuits.
The minimum operating temperature for this model is -40°C, making it suitable for use in harsh environments.
It can deliver an output current of up to 15 mA, which is sufficient for driving moderate loads directly.
The input bias current is 400 pA, which enhances the precision of the amplifier in signal processing applications.
The dimensions of the SOT-23 package are approximately 2.92 mm in length, 1.6 mm in width, and 1.02 mm in height.
The slew rate of this operational amplifier is 1 V/μs, which is suitable for moderate-speed applications.
Yes, the LMP7701MF/NOPB is compliant with RoHS standards, ensuring it meets environmental safety requirements.
The input offset voltage is low at 500 μV, which helps to improve the accuracy of the amplifier.
This operational amplifier is a single-channel device, designed for various applications in electronics.
The maximum operating temperature for this model is 125°C, allowing it to function in demanding industrial environments.
This operational amplifier uses a surface mount configuration, specifically in a SOT-23 package.
