Microchip Complex Programmable Logic Device EEPROM 32 Macro Cells 32 I/O 25 ns 2 Logic Blocks In-System ATF1502ASL-25AU44

Microchip ATF1502ASL-25AU44 is a complex programmable logic device (CPLD) with EEPROM memory technology. It contains 32 macro cells and 32 user input/output pins, capable of operating at high speeds with a maximum propagation delay time of 25 ns.

This logic device supports in-system programmability, enabling developers to program or reprogram the device without removing it from the circuit, ideal for iterative development and deployment.

It is packaged in a 44-pin Thin Quad Flat Package (TQFP) designed for surface mount assembly, providing a compact and reliable form factor for embedded and industrial applications.

The device operates within a supply voltage range from 4.75 volts to 5.25 volts and supports individual output enable control for advanced logic management. Its operating temperature range from -40°C to 85°C makes it suitable for various operating environments including industrial and commercial electronics.

With a maximum operating frequency of 125 MHz, it delivers fast and efficient logic processing. Physical dimensions of height 1.05 mm and length 10.1 mm contribute to its compact profile ideal for space-constrained hardware designs.

This CPLD is targeted for applications in embedded systems, electronic development, and programmable logic implementations where flexibility, speed, and reliability are required. This device supports in-system programmability for flexible application development.

It is mounted in a 44-pin TQFP package suitable for surface mount technology. The device operates within a supply voltage range of 4.75V to 5.25V and supports individual output enable control. Operating temperature ranges from -40°C to 85°C ensuring reliable performance in varied environments.

Designed for use in embedded systems requiring re-programmability and fast logic operations. The maximum operating frequency is 125 MHz for high-speed logic applications. Compact device dimensions include a height of 1.05 mm and length of 10.1 mm.

The product is compliant with standard semiconductor industry practices but does not hold automotive certification.

Microchip provides comprehensive support tools including software for PCB and 3D mechanical design, enabling efficient development cycles in electronic design automation (EDA) environments.

EnvMart offers this Microchip complex programmable logic device as a key component for semiconductor needs within industrial, laboratory, and manufacturing sectors.
