Microchip Simple Programmable Logic Device 150 Gates, 8 Macro Cells, 8 I/O, 62 MHz In System Programmability ATF16V8B
Specifications
| Country of Origin | India |
|---|---|
| Brand | Microchip |
| Height | 2.35mm |
| Length | 12.8mm |
| Model | ATF16V8B |
| Mount Type | Surface |
| Series | ATF16V8B |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS |
| Pin Count | 20 |
| Maximum Supply Voltage | 5V |
| Minimum Supply Voltage | 4.5V |
| Maximum Propagation Delay Time | 15ns |
| Number of Gates | 150 |
| Number of Macro Cells | 8 |
| Number of User I/Os | 8 |
| Maximum Internal Frequency | 62MHz |
Key Features
- Supports in system programmability enabling flexible device configuration.
- Re-programmability support provides versatility for design adjustments.
- Surface mount type with a 20-pin SOIC package ensures easy PCB integration.
- Operates with supply voltage ranging from 4.5V to 5V.
- Wide operating temperature range from -40°C to 85°C for reliable industrial use.
- Low maximum propagation delay time of 15ns ensures quick signal processing.
- Compact dimensions with a length of 12.8mm and height of 2.35mm.
- Supports RoHS compliance guaranteeing environmental safety.
Product Description
Microchip ATF16V8B is an advanced Simple Programmable Logic Device designed for industrial and electronic applications requiring customizable logic functions. With 150 gates and 8 macro cells, this device enables complex logic configurations. It features 8 user I/O pins, supporting a maximum internal frequency of 62 MHz, allowing high-speed signal processing suitable for embedded systems and automation.
This model supports in system programmability and re-programmability, providing engineers with the flexibility to update and modify logic designs without replacing the hardware, ideal for prototyping and production lines.
The compact 20-pin SOIC surface-mount package with dimensions of 12.8mm length and 2.35mm height facilitates high-density mounting on printed circuit boards (PCBs). It operates reliably in a voltage range from 4.5V to 5V and within a wide operating temperature range of -40°C to 85°C, ensuring stable performance in diverse environmental conditions.
In system programmability for flexible logic design. Re-programmability support for design updates. Surface mount type SOIC package with 20 pins. Supply voltage: 4.5V to 5V. Operating temperature: -40°C to 85°C. Maximum internal frequency up to 62 MHz.
Maximum propagation delay time of 15ns. RoHS compliant for environmental standards.
This programmable logic device is widely used in industrial automation, embedded systems development, and electronic circuit design applications, enabling efficient logic handling and customization for complex control tasks.
Explore more options in programmable logic devices and semiconductor components at EnvMart for your industrial and electronic projects.
Explore more products in our Programmable Logic ICs category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum internal frequency of this model is 62 MHz, allowing for high-speed signal processing suitable for various applications.
It operates with a supply voltage ranging from 4.5V to 5V, ensuring compatibility with standard electronic systems.
This model features 8 user I/O pins, providing flexibility for various circuit configurations.
The maximum propagation delay time is 15 ns, which allows for quick signal processing in applications.
It has a length of 12.8 mm and a height of 2.35 mm, making it suitable for high-density PCB mounting.
The ATF16V8B comes in a 20-pin SOIC surface mount package, facilitating easy integration into printed circuit boards.
It operates within a wide temperature range from -40°C to 85°C, ensuring reliable performance in various environments.
Yes, this model is RoHS compliant, ensuring it meets environmental safety standards.
This device features 150 gates and 8 macro cells, allowing for complex logic configurations.
It is widely used in industrial automation, embedded systems development, and electronic circuit design applications.
In-system programmability allows for flexible logic design and re-programmability, enabling updates without hardware replacement.
The country of origin for this model is India, indicating its manufacturing location.
