Wurth Elektronik WE-PD 1210 Shielded Wirewound Surface Mount Inductor 470 µH ±20 % 1.4 A Idc Ferrite Core 7447709471
Specifications
| Country of Origin | India |
|---|---|
| Brand | Wurth Elektronik |
| Height | 10mm |
| Length | 12mm |
| Depth | 12mm |
| Packaging | Tape & Reel |
| Series | WE-PD |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 470μH |
| Standards/Approvals | IEC 62024-2-2020, JEDEC JS709B, RoHS, REACH |
| Package/Case | 1210 |
| Maximum DC Current | 1.4A |
| Maximum DC Resistance | 560mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 2MHz |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
| Recommended solder profile | Reflow |
Key Features
- Features a 1210 package case with tape and reel packaging for efficient surface mount assembly.
- Magnetically shielded design reduces leakage magnetic fields for improved circuit performance.
- Constructed with wirewound inductor construction and ferrite core material for durability.
- Operates reliably across a temperature range of -40°C to 125°C compliant with AEC-Q200 automotive standard.
- Maximum DC resistance is 560 mΩ with an inductance tolerance of ±20% ensuring stable operation.
- Designed for switching regulators, integrated DC/DC converters, and high-efficiency applications over 86%.
- Complies with IEC 62024-2-2020, JEDEC JS709B, RoHS, and REACH standards for quality and environmental safety.
Product Description
Wurth Elektronik 7447709471 WE-PD series shielded wirewound surface mount inductor delivers 470 µH inductance with ±20% tolerance and a maximum DC current rating of 1.4 A. This inductor uses a ferrite core housed in a 1210 package case and features tape and reel packaging, optimizing it for automated surface mount technology (SMT) assembly.
The magnetically shielded design effectively reduces leakage magnetic fields, which enhances circuit reliability in sensitive applications. The wirewound construction on a metal base ensures high storage capacity and low self-losses, allowing for the highest possible current loading among SMD inductors.
Engineered to operate across a wide temperature range from -40°C to +125°C and certified to meet AEC-Q200 automotive standards, this component suits demanding environments in automotive and industrial electronics.
It features a maximum DC resistance of 560 mΩ and a maximum self-resonant frequency of 2 MHz, supporting stable switching regulator operation and integrated DC/DC converters with extremely high efficiency (>86%). Recommended for electronic circuits needing reliable inductors such as switching regulators or graphic cards, this component is RoHS and REACH compliant, adhering to international environmental directives.
1210 package with tape and reel packaging for surface mount applications. Magnetically shielded to minimize leakage field effects in circuits. Ferrite core and wirewound construction ensure performance and durability. Suitable for switching regulators with low operating voltages and high efficiency.
Automotive standard certified, meeting rigorous environmental and quality standards. Operating temperature range supports industrial and automotive conditions. Compliant with IEC 62024-2-2020, JEDEC JS709B, RoHS, and REACH standards.
This Wurth Elektronik WE-PD series inductor is ideal for industrial, automotive, and electronic manufacturing sectors requiring high-quality, reliable Surface Mount Inductors for power electronics. EnvMart offers this component to support high-performance switching regulator and converter designs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model features an inductance value of 470 µH with an inductance tolerance of ±20%.
The maximum DC current rating for this unit is 1.4 A.
The dimensions of this inductor are 12mm in length, 12mm in depth, and 10mm in height.
It operates reliably across a temperature range of -40°C to +125°C.
The maximum DC resistance is 560 mΩ.
This inductor is constructed with a ferrite core material.
It comes in tape and reel packaging, which is optimized for surface mount assembly.
It complies with IEC 62024-2-2020, JEDEC JS709B, RoHS, and REACH standards.
The maximum self-resonant frequency is 2 MHz.
It is recommended for use in switching regulators, integrated DC/DC converters, and high-efficiency applications.
This unit features a wirewound construction, which contributes to its performance characteristics.
Yes, it is certified to meet AEC-Q200 automotive standards, making it suitable for automotive environments.
