Wurth Elektronik WE-TPC 5828 Shielded Wirewound Surface Mount Inductor with Ferrite Core 47 µH ±30% 820 mA Idc 744053470

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik WE-TPC 5828 Shielded Wirewound Surface Mount Inductor with Ferrite Core 47 µH ±30% 820 mA Idc 744053470

Name: Wurth Elektronik WE-TPC 5828 Shielded Wirewound Surface Mount Inductor with Ferrite Core 47 µH ±30% 820 mA Idc 744053470
Brand: Wurth Elektronik
SKU: 199148
Price: 1.75 USD
Availability: InStock



Category Surface Mount Inductor Brand Wurth Elektronik Condition New

Specifications

Country of Origin	China
Brand	Wurth Elektronik
Operating Temperature	- 40 to +125°C
Height	2.8mm
Length	5.8mm
Depth	5.8mm
Packaging	Tape & Reel
Series	WE-TPC
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-40°C
Core Material	Ferrite
Inductance	47μH
Package/Case	5828
Maximum DC Current	820mA
Maximum DC Resistance	250mΩ
Inductance Tolerance	±30 %
Termination Style	Surface Mount
Maximum Self Resonant Frequency	13MHz
Inductor Construction	Wirewound
Automotive Standard	AEC-Q200
Standards/Approvals IEC 60286-3	2013, IEC 61249-2-21, IPC/JEDEC J-STD-020E, JEDEC JS709B, REACH, RoHS

Key Features

The inductor supports a maximum DC current of 820 mA for reliable performance.
Its compact 5828 package with dimensions 5.8mm x 5.8mm x 2.8mm ensures space-efficient PCB mounting.
Constructed with a ferrite core for enhanced magnetic characteristics and shielding to minimize interference.
Rated for operating temperatures from -40°C to +125°C suitable for automotive standard AEC-Q200.
Features surface mount termination style for automated assembly and tape & reel packaging format.
Maximum DC resistance is 250 milliohms ensuring efficient current flow with minimal loss.
Self-resonant frequency is 13 MHz providing stable performance in high-frequency circuits.

Product Description

Wurth Elektronik 744053470 WE-TPC 5828 shielded wirewound surface mount inductor with a ferrite core features a nominal inductance of 47 µH with ±30% tolerance and a maximum DC current rating of 820 mA. This flat power inductor is part of the WE-TPC series designed for applications requiring high current capability and magnetic shielding that reduces leakage fields.

The inductor dimensionally measures 5.8 mm in length and depth with a height of 2.8 mm and is housed in a 5828 package suitable for surface mount PCB assembly. It is constructed using high-quality ferrite core material and wirewound technology, resulting in high performance and stability across operating temperature ranges from -40°C up to 125°C. Meeting automotive standard AEC-Q200, this component is fit for demanding environments.

Its shielding minimizes electromagnetic interference, and with a maximum DC resistance of 250 milliohms and a self-resonant frequency of 13 MHz, it supports efficient signal and power management. Ideal for use in embedded power supplies, DC/DC converters, portable electronics, telemetric devices, and other industrial electrical systems.

This product conforms with key international standards and environmental regulations, including IEC 60286-3:2013, IEC 61249-2-21, IPC/JEDEC J-STD-020E, JEDEC JS709B, REACH, and RoHS, ensuring reliability and compliance for industrial and automotive applications.

The inductor supports high current throughput with 820 mA maximum DC current rating. Compact 5828 package aids integration into space-constrained PCB layouts. High-quality ferrite core with magnetic shielding reduces electromagnetic interference.

Wide temperature operating range from -40 to +125°C for automotive and industrial environments. Surface mount termination enables efficient automated assembly. Low DC resistance of 250 mΩ optimizes power efficiency. High self-resonant frequency of 13 MHz suitable for high-frequency electronics.

Complies with multiple international quality and safety standards.

This Wurth Elektronik WE-TPC series Surface Mount Inductor is an excellent choice for design engineers requiring reliable, compact inductors for power electronics applications. Browse the Electronics Components category at EnvMart for a wide range of inductors and related passive components to complement your projects.
