3M 3000 Series Right Angle Through Hole PCB Header 64 Contacts 2.54 mm Pitch 2 Row Shrouded N3764-5202RB

Free Delivery in India | Lowest Global Shipping Charges

3M 3000 Series Right Angle Through Hole PCB Header 64 Contacts 2.54 mm Pitch 2 Row Shrouded N3764-5202RB



Category PCB Header Brand 3M Condition New

Specifications

Country of Origin	India
Voltage	25V
Brand	3M
Orientation	Right Angle
Current	1A
Model	N3764-5202RB
Mount Type	Through Hole
Housing Material	Glass Filled Polyester
Contact Material	Copper Alloy
Series	3000
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	64
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Board-to-Board, Wire-to-Board
Tail Pin Length	0.01in
Mating Pin Length	6.2mm

Key Features

This 2-row PCB header features a 2.54 mm pitch for standard circuit board compatibility.
Constructed with a rugged glass filled polyester housing for enhanced durability.
Contacts are made of copper alloy with gold plating ensuring reliable conductivity and corrosion resistance.
Designed for board-to-board and wire-to-board connector systems with male contact gender.
Supports a maximum operating temperature of 105°C and minimum of -55°C for wide environmental tolerance.
Mount type is through hole with solder termination ensuring strong mechanical and electrical connection.
Includes features such as short tail pin length of 0.01 inch and mating pin length of 6.2 mm for precise fit.

Product Description

3M N3764-5202RB is a high-quality 3000 Series right angle through hole PCB header featuring 64 contacts arranged in 2 rows with a 2.54 mm pitch. This shrouded connector is designed for robust electrical engineering applications including electronics manufacturing and assembly.

The body is crafted from glass filled polyester providing excellent mechanical strength and thermal stability. Copper alloy contacts with gold plating ensure excellent conductivity and corrosion resistance under demanding conditions.

Its right angle orientation and through hole mounting make it ideal for board-to-board and wire-to-board connector systems, allowing for compact and reliable circuit connections. The header supports a voltage rating of 25 V and a current of 1 Amp, suitable for low voltage electronic circuits.

Operating temperature ranges from -55°C to a maximum of 105°C, thus viable for use in diverse industrial settings including testing, instrumentation, and electronic devices exposed to wide temperature variations.

Additional features include male contact gender, solder termination type, short tail pin length of 0.01 inch, and a mating pin length of 6.2 mm ensuring proper engagement and locking in circuit assemblies. The shrouded design offers added protection to contacts against accidental shorts or damage.

This PCB Header supports board-to-board and wire-to-board connector systems. Durable housing made of glass filled polyester withstands harsh conditions. Gold-plated copper alloy contacts offer excellent electrical performance.

Right angle through hole mount allows versatile PCB assembly configurations. Rated for 25 V and 1 A electrical load for low power applications. Wide operating temperature range from -55°C to 105°C for industrial use. Male contact with solder termination ensures secure electrical connectivity.

Shrouded construction protects contacts and enhances durability.

This connector is suitable for industrial, electronics manufacturing, automation, instrumentation, and power distribution applications. Its reliable construction and precise specifications make it an essential component for engineers and technicians working with PCB assemblies.

Explore more quality connectors and electronics components at EnvMart to fulfill your industrial and manufacturing requirements.
