JAE MIL Spec Circular Connector Copper Alloy Straight 17 Way Box Mount, Female Black Shell, Male Contacts N/MS3102A20-29P
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | 500V ac |
| Brand | JAE |
| Colour | Black |
| Orientation | Straight |
| Current | 13A |
| Model | N/MS3102A20-29P |
| Mount Type | Box Mount |
| Housing Material | Zinc |
| Contact Material | Copper Alloy |
| Series | N/MS |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -30°C |
| Contact Plating | Silver |
| Number of Contacts | 17 |
| Contact Gender | Male |
| Connector Gender | Female |
| Shell Size | 20 |
| Military Standard | MIL-5015 |
| Connector Size | Standard |
| Shell Plating | Zinc |
Key Features
- Features 17 male contacts for secure electrical connections.
- Rated for 13A current and 500V AC voltage for reliable power transfer.
- Consists of a black female shell with zinc plating for corrosion resistance.
- Constructed with zinc housing material and copper alloy contact material ensuring durability.
- Designed to meet MIL-5015 military standards with a standard connector size and straight orientation.
- Suitable for solder termination type enhancing connectivity stability.
- Operates efficiently in a temperature range from -30°C to 85°C.
- Shell size is 20, ideal for various industrial and electronic circular connector needs.
Product Description
JAE N/MS3102A20-29P MIL Spec Circular Connector is a precision-engineered component for demanding electronic and electrical applications. This connector features a copper alloy construction with a straight orientation and a robust box mount design. It includes 17 male contacts housed within a black female shell plated with zinc to resist corrosion and provide reliable long-term usage.
The connector operates at 13 amps current and supports voltages up to 500V AC, making it suitable for power and signal transmission in industrial, military, aerospace, and manufacturing environments. It is compliant with MIL-5015 standards, offering high reliability under harsh conditions.
Designed with a solder termination type, the connector ensures secure and stable connection within assemblies. The zinc housing and silver-plated contacts combine durability with excellent conductivity. With an operating temperature range from -30°C to 85°C, it withstands extreme environments without degradation.
This MIL Spec Circular Connector, with shell size 20 and standard connector size, is widely used in industrial circular connector assemblies requiring dependable mechanical and electrical performance. The high-quality materials and precision manufacturing from Japan guarantee consistent quality and performance.
The product is ideal for applications in industrial automation, military electronics, aviation, and other sectors requiring rugged connectors. It facilitates secure, high-current connections with effective resistance to environmental stress.
Features 17 male contacts for secure electrical connections. Rated for 13A current and 500V AC voltage for reliable power transfer. Consists of a black female shell with zinc plating for corrosion resistance. Constructed with zinc housing material and copper alloy contact material ensuring durability.
Designed to meet MIL-5015 military standards with a standard connector size and straight orientation. Suitable for solder termination type enhancing connectivity stability. Operates efficiently in a temperature range from -30°C to 85°C.
Shell size is 20, ideal for various industrial and electronic circular connector needs. Silver plating on contacts improves conductivity and wear resistance. Manufactured in Japan with strict quality assurance. Explore more high-quality Mil Spec Circular Connectors like the JAE N/MS3102A20-29P at EnvMart for your precision electrical component needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The connector is rated for a maximum voltage of 500V AC, ensuring reliable power transfer in various applications.
This model features 17 male contacts, designed for secure electrical connections.
It is rated for a current of 13A, suitable for high-current applications.
The connector operates efficiently within a temperature range of -30°C to 85°C, making it suitable for various environments.
This connector is designed with a solder termination type, enhancing connectivity stability.
The housing is made of zinc, while the contacts are constructed from copper alloy, providing durability and conductivity.
Yes, it is designed to meet MIL-5015 military standards, ensuring high reliability under demanding conditions.
The shell size for this model is 20, suitable for various industrial and electronic applications.
The connector features a straight orientation, which is common for box mount applications.
The shell is black and is plated with zinc for corrosion resistance.
It is manufactured in Japan, ensuring strict quality assurance during production.
This model is suitable for applications in industrial automation, military electronics, aviation, and other sectors requiring rugged connectors.
