Glenair Copper Alloy Straight 3 Way Cable MIL Spec Circular Connector Male, Male Contacts, Shell Size 14 IT3106A14S7PPHM
Specifications
| Country of Origin | Italy |
|---|---|
| Voltage | 500, 700V ac |
| Brand | Glenair |
| Orientation | Straight |
| Current | 22A |
| Model | IT3106A14S7PPHM |
| Mount Type | Cable |
| Housing Material | Aluminium Alloy |
| Contact Material | Copper Alloy |
| Series | IT |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Contact Plating | Gold, Silver |
| Number of Contacts | 3 |
| Contact Gender | Male |
| Connector Gender | Male |
| Shell Size | 14 |
| Military Standard | MIL-DTL-5015 |
| Mating Type | Threaded |
| Connector Size | Standard |
| Shell Plating | Olive Drab Cadmium |
Key Features
- The connector features 3 male contacts ensuring secure electrical connections.
- Designed with a straight orientation and threaded mating type for robust assembly.
- Operates under MIL-DTL-5015 standard, suitable for harsh environments.
- Supports currents up to 22A and voltages of 500 and 700V AC.
- Constructed with aluminium alloy housing with olive drab cadmium plating for corrosion resistance.
- Contact plating includes gold and silver to ensure excellent conductivity and durability.
- Suitable for operating temperatures ranging from -55°C to 125°C.
- Ideal for military, industrial, aerospace, and harsh environment electronics applications.
Product Description
The Glenair IT3106A14S7PPHM is a premium MIL Spec Circular Connector designed for cable mounting applications demanding high reliability and durability. Constructed with a copper alloy for contacts and an aluminium alloy housing, it provides excellent mechanical strength and resistance to corrosion, enhanced by the olive drab cadmium plating on the shell.
This connector features 3 male contacts configured in a straight orientation and secured using threaded mating types, ensuring stable and secure connections in demanding electronic environments. It complies with MIL-DTL-5015 military standards, making it suitable for military, aerospace, industrial, and harsh environment electronics.
Operating with a current rating of 22A and voltage capabilities of 500 and 700V AC, the connector supports a wide range of power applications. The contact plating of gold and silver guarantees excellent electrical conductivity and resistance to wear, essential for long-life usage.
The connector operates reliably in temperatures ranging from -55°C to 125°C, making it suitable for extreme environmental conditions. Its solder termination type supports secure wiring for cable mounting configurations with shell size 14, designed as standard size for various industrial connectors.
The product is made in Italy, reflecting high manufacturing standards and precision quality control. The connector offers three male contacts for versatile cable connections. Threaded mating eliminates accidental disconnections and improves mechanical robustness.
Construction materials and plating provide enhanced corrosion resistance and electrical performance. Operating temperature range supports use in varied environmental conditions. Compliance with MIL-DTL-5015 standard ensures suitability for military and industrial usage.
Suitable for applications requiring 22A current and up to 700V AC voltage. Straight orientation and cable mount style facilitate easy installation in constrained spaces. Manufactured in Italy guaranteeing adherence to strict quality standards.
Browse EnvMart’s Mil Spec Circular Connectors category for more industrial-grade connectors from trusted brands like Glenair.
