Molex PicoBlade Series Straight Surface PCB Header 9 Contacts 1.25mm Pitch 1 Row Shrouded 53398-0971
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 125V |
| Brand | Molex |
| Orientation | Straight |
| Current | 1A |
| Mount Type | Surface |
| Housing Material | Nylon |
| Contact Material | Phosphor Bronze |
| Series | PicoBlade |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 1.25mm |
| Contact Plating | Tin |
| Number of Contacts | 9 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 0.6mm |
Key Features
- Designed with a compact 1.25 mm pitch to optimize PCB space utilization.
- Constructed using durable nylon housing with phosphor bronze contacts plated in tin.
- Supports a current rating of 1A and operates up to 125V.
- Features a straight, shrouded male connector suitable for surface mount assembly.
- Operates reliably in temperature ranges from -40°C to 105°C.
- Termination is solder type, ensuring strong, long-lasting joints.
- Compatible with the PicoBlade connector system for precise and secure interconnections.
Product Description
Molex 53398-0971 PicoBlade Series Straight Surface PCB Header is engineered to provide precision and dependable wire-to-board connections in a compact form factor. It features 9 male contacts arranged in a single row with a 1.25 mm pitch, designed for surface mount applications in electronic circuit boards.
This PCB header incorporates a shrouded housing made of durable nylon material that offers protection to the contacts while facilitating easy mate and demate cycles. The phosphor bronze contacts plated with tin ensure efficient conductivity and corrosion resistance while supporting a current rating of 1A and a voltage rating of 125V for safe and reliable signal transmission.
Built to withstand environmental challenges, this connector operates effectively within a temperature range of -40°C to 105°C, making it suitable for demanding industrial, automation, and electronics manufacturing environments.
It utilizes solder termination for secure mechanical and electrical connections on printed circuit boards. The connector is recognized for its compact footprint, minimizing PCB space usage without compromising on durability or performance.
The Molex PicoBlade system is ideal for applications such as automation equipment, electronic instrumentation, and mechanical systems requiring reliable and precise PCB connectivity solutions. This model is specifically designed to mate with compatible PicoBlade housings, allowing flexible configuration in diverse industrial setups.
Compact 1.25 mm pitch supports dense PCB layouts. Durable nylon housing provides mechanical protection. Phosphor bronze, tin-plated contacts for reliable conductivity. Rated for 1A current and 125V voltage. Operates in temperatures from -40°C to 105°C.
Solder termination ensures strong PCB mounting. Shrouded, straight male connector design. Compatible with PicoBlade housing options.
This product is new and made in India, ensuring high manufacturing standards. Molex PicoBlade series connectors are widely used across electronics manufacturing, automation, and industrial control sectors.
Explore the full range of Molex PCB connectors and related components on EnvMart to find precise solutions tailored to your project needs.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch size of this PCB header is 1.25 mm, designed to optimize PCB space utilization.
It supports a current rating of 1A and operates at a voltage rating of 125V for safe signal transmission.
The contacts are made of phosphor bronze and are plated with tin to ensure efficient conductivity and corrosion resistance.
This connector operates effectively within a temperature range from -40°C to 105°C, making it suitable for various environments.
This model features 9 male contacts arranged in a single row.
It utilizes solder termination, ensuring strong mechanical and electrical connections on printed circuit boards.
Yes, it is compatible with the PicoBlade connector system, allowing for precise and secure interconnections.
This model features a straight orientation, suitable for surface mount assembly.
The housing is constructed from durable nylon, providing mechanical protection to the contacts.
This product is manufactured in India, ensuring adherence to high manufacturing standards.
It supports a wire-to-board connector system, designed for reliable connections in electronic applications.
The tail pin length is 0.6 mm, suitable for soldering onto printed circuit boards.
