TE Connectivity Surface Power Relay 12V dc Coil 4A Switching Current SPDT 1462042-9

TE Connectivity 1462042-9 Surface Power Relay is a high-performance compact device designed for applications requiring reliable switching of electrical loads. Featuring a 12V dc coil and single-pole double-throw (SPDT) contact configuration, this surface mount relay offers switching currents of up to 4A at voltages of 220V dc and 220V ac.

The relay's slim dimensions - 10mm length, 6mm width, and 5.7mm height - allow easy integration into modern printed circuit boards where space is limited. Its coil power consumption of 140mW supports efficient energy usage, and the coil resistance of 1kΩ contributes to stable operation.

Constructed with palladium and ruthenium contacts, the relay ensures superior conductivity and long-term durability. It is hermetically sealed to an IP67 equivalent standard, offering protection against dust and water ingress, along with excellent resistance to mechanical shocks up to 300G functional and 500G survival. The relay also meets stringent surge capability requirements, complying with Telcordia GR 1089, FCC Part 68, and ITU-T K20,21,45 standards.

This power relay is suitable for diverse industrial applications including telecommunications equipment, optical network terminals, office electronics, test and measurement instruments, medical devices, and automotive systems. The operating temperature range of -40°C to 85°C makes it adaptable to various environmental conditions.

The IM series slimline design minimizes board space to approximately 60mm², enabling compact device designs without sacrificing performance. This power relay features a low profile with dimensions 10x6x5.7 mm for space-efficient PCB mounting.

The coil voltage is 12V dc and coil power consumption is only 140mW, improving energy efficiency. Constructed with hermetically sealed contacts made of palladium and ruthenium for durability and reliability. Capable of switching currents of 4A at both 220V dc and 220V ac voltages.

Designed to resist mechanical shocks up to 300G functional and high surge voltages ensuring stable operation under harsh conditions. Meets RoHS compliance and international surge standards suitable for telecommunications and automotive use.

The relay is IP67-equivalent sealed, protecting against dust and moisture ingress. Offers broad application versatility including in telecommunications, medical equipment, automotive, and office devices. Explore the extensive range of Power Relays and related components at EnvMart for quality and reliability in your electronic design projects.
