Panasonic PCB Power Relay 12V DC Coil 10A Switching Current SPDT ALQ112

Panasonic ALQ112 is a PCB Power Relay featuring a 12V DC coil voltage and 10A switching current with SPDT contact configuration. It belongs to the ALQ series, known for compact size combined with high switching capacity and reliable performance under strenuous conditions.

This relay measures 20mm in length, 10mm in width, and 15.6mm in height. The coil resistance is 360Ω and coil power consumption is 400mW, making it efficient for low power applications. It supports switching DC voltage up to 30V and AC voltage up to 250V, switching power rating of 500VA, and contact resistance of 100mΩ.

The relay’s contact material is silver alloy, ensuring durability and consistent performance. Designed for PCB mounting with PCB pins, it is suitable for integration into compact electronic designs. Ambient operating temperature range is -40°C to +85°C, allowing deployment in harsh environments.

Key safety and quality certifications include CQC, cUL, VDE, UL, cULus, and CSA. High surge voltage capacity of 8000 V and breakdown voltage of 4000 V ensure robust operation in industrial and commercial applications.

Typical use cases for the Panasonic ALQ112 power relay include appliances such as refrigerators, cooking ovens, washing machines, and air conditioners. It is also ideal for motor controls, robots, and various power supply equipment, making it versatile for industrial automation, HVAC, manufacturing, and home appliance sectors.

The relay operates with a 12V DC coil voltage. It supports single pole double throw (SPDT) contact configuration. Capable of switching currents up to 10A at 250V AC and 30V DC. Compact dimensions of 20mm length, 10mm width, and 15.6mm height.

Suitable for ambient temperatures ranging from -40°C to +85°C. Contact material is durable silver alloy ensuring low contact resistance. Designed for PCB mounting with PCB pin terminals. Features high insulation resistance and surge voltage tolerance up to 8000 V.

Applications include appliances, industrial equipment, robot controllers, and power supplies. Manufactured in Thailand ensuring quality production standards.
