TE Connectivity 2-Way 3.96mm Pitch Shrouded IDC Female Cable Connector 600V AC 7A MTA-156 Series 3-640428-2
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 600V ac |
| Brand | TE Connectivity |
| Orientation | Right Angle |
| Current | 7A |
| Mount Type | Cable |
| Housing Material | Nylon |
| Contact Material | Copper |
| Series | MTA-156 |
| Termination Type | IDC |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 3.96mm |
| Contact Plating | Tin over Nickel |
| Number of Contacts | 2 |
| Contact Gender | Female |
| Connector Gender | Female |
| Shrouded/Unshrouded | Shrouded |
Key Features
- The connector has 2 female contacts arranged in 1 row.
- It features an insulation displacement contact (IDC) termination type.
- Rated for 600V AC voltage with tin over nickel contact plating.
- Constructed with a nylon housing providing durability and insulation.
- Suitable for wire sizes from 22 AWG, ensuring secure connection.
- Operates in a temperature range of -55°C to 105°C.
- Right angle cable mount type enables space-saving installations.
- Shrouded design prevents reverse mating and enhances safety.
Product Description
TE Connectivity 3-640428-2 2-Way IDC Female Connector is an electrical cable connector designed for high reliability and efficient termination. Featuring a 3.96mm pitch and shrouded housing, this IDC (Insulation Displacement Contact) connector ensures quick assembly without wire stripping, supporting discrete wire sizes from 22 AWG. It is rated for 7 amps current and 600 volts AC operation, suitable for various industrial and electronic applications.
The connector incorporates female tin-over-nickel plated copper contacts housed in durable nylon material rated UL94V-2. Its right-angle cable mount design optimizes space in wiring assemblies and provides stable mechanical support. Operating temperature ranges from -55°C to 105°C make it well suited for demanding environments.
The MTA-156 series connectors by TE Connectivity are used extensively for wire-to-wire and wire-to-board interconnections in electronics manufacturing, automotive, communications, and consumer devices. The shrouded design with molded ribs prevents accidental mis-mating and ensures polarization for correct assembly.
2 female contacts in a single row for compact configuration. IDC termination type enables fast, tool-assisted wire connections. Supported wire size includes 22 AWG discrete wire. Housing made of nylon 6/6 with UL94V-2 flammability rating.
Contact plating provides corrosion resistance and reliable conductivity. Suitable for applications requiring up to 7A current and 600V AC voltage. Wide operating temperature range for versatile industrial use.
This connector is ideal for applications in industrial equipment, automotive wiring harnesses, electronic assemblies, telecommunications, HVAC controls, and commercial electronics. Its reliable mechanical and electrical properties reduce assembly time and cost while ensuring consistent connection quality.
Explore further TE Connectivity IDC Connectors and related products on EnvMart for integrated electronics solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The connector is rated for 600V AC operation.
It supports a current rating of 7A.
This model is suitable for wire sizes from 22 AWG.
It operates within a temperature range of -55°C to 105°C.
It features an insulation displacement contact (IDC) termination type.
The connector has a pitch of 3.96mm.
It has 2 female contacts arranged in a single row.
The housing is constructed from nylon material.
It features a right-angle orientation for cable mounting.
It is suitable for applications in industrial equipment, automotive wiring harnesses, and electronic assemblies.
The contacts are plated with tin over nickel for corrosion resistance.
The connector is manufactured in India.
