Preci-Dip 813 Series Straight Through Hole Spring Loaded Connector, 12 Contacts, 2.54 mm Pitch, 2 Row 813-S1-012-10-017101

Preci-Dip 813-S1-012-10-017101 Spring Loaded Connector provides a precision solution for electronic and industrial applications requiring durable and reliable PCB connections. This model features 12 spring-loaded contacts arranged in 2 rows with a standard 2.54 mm pitch, designed for through hole mounting. The shrouded housing made from fibreglass reinforced polyethylene terephthalate enhances mechanical strength and environmental protection.

The connector's brass contacts with gold plating ensure excellent electrical conductivity and corrosion resistance. Its spring-loaded mechanism guarantees low and stable electrical resistance without micro-discontinuities, even under vibration or movement, making it highly suitable for use in industrial automation, manufacturing equipment, and laboratory instruments.

Operable within a wide temperature range of -55°C to 125°C and rated for 3.5A current and 150V voltage, this connector supports robust performance in demanding environments. The straight orientation and male contact design facilitate standard PCB assembly with solder termination.

The plunger stroke length is 1.4 mm with a plastic body height of 4 mm, ensuring reliable and consistent contact pressure. The shrouded design provides protection against mechanical damage and short circuits, extending product life in harsh industrial conditions.

Preci-Dip spring-loaded connectors offer a superior alternative to conventional connection solutions by maintaining stable electrical performance over long-term use. They are widely used in industrial tools, electronics manufacturing, and test equipment for ensuring dependable multi-point electrical connections.

Utilizes spring-loaded contacts for low and stable electrical resistance. Constructed with brass contacts plated in gold for optimal conductivity. Housing made of fibreglass reinforced polyethylene terephthalate for durability.

Operates reliably between -55°C and 125°C temperature range. Rated for a voltage of 150V and current of 3.5A. Designed with a straight orientation and male contact gender for PCB connectivity. Plunger stroke length of 1.4 mm ensures flexible contact engagement.

Complies with UL 94V-0 standards for flame retardance. Offers a shrouded design to protect contacts against damage and short circuits. Ideal for industrial, electronics, and automated machinery applications requiring reliable electrical connections.
