Texas Instruments Adjustable Low Dropout (LDO) Voltage Regulator 30V 3-Pin Surface Mount LM1086IS-ADJ/NOPB
Specifications
| Country of Origin | India |
|---|---|
| Voltage | Regulators Texas Instruments LM1086IS-ADJ/NOPB, Voltage Regulator 30V 3-Pin RS S |
| Brand | Texas Instruments |
| Height | 4.57mm |
| Length | 10.16mm |
| Model | LM1086IS-ADJ/NOPB |
| Width | 8.64mm |
| Mount Type | Surface |
| Series | LM1086 |
| Maximum Operating Temperature | 125°C |
| Polarity | Positive |
| Maximum Input Voltage | 30V |
| Quiescent Current | 5mA |
| Minimum Input Voltage | 2.6V |
| Pin Count | 3 |
Key Features
- Provides adjustable output voltage with low dropout characteristics.
- Operates efficiently with a maximum input voltage of 30 volts.
- Features a low quiescent current of 5 mA to optimize power consumption.
- Offers high maximum operating temperature rating of 125°C for reliable performance.
- Three-pin configuration facilitates easy PCB integration.
- Ensures stable voltage regulation with excellent line voltage regulation and low noise.
- Designed for use in power management applications in electronics and industrial circuits.
- Comes without automotive standard compliance, suitable for general electronics use.
Product Description
The Texas Instruments LM1086IS-ADJ/NOPB is an adjustable Low Dropout (LDO) linear voltage regulator designed to provide efficient and stable voltage regulation for various electronics applications. It supports a maximum input voltage of 30 volts and utilizes a positive polarity configuration in a compact surface mount package, measuring 10.16 mm in length, 8.64 mm in width, and 4.57 mm in height.
With a low quiescent current of just 5 mA, this regulator minimizes power consumption while maintaining output voltage precision. It is designed to operate reliably up to 125°C, ensuring stable performance in demanding industrial, consumer electronics, and power management systems.
The device features a 3-pin configuration optimized for easy PCB mounting and integration. Its adjustable output allows designers to tailor the voltage to specific circuit requirements, making it suitable for a wide range of applications in power supplies, battery chargers, and embedded systems.
This Texas Instruments voltage regulator does not have automotive standard certification but offers high performance for general industrial and laboratory power electronics environments. Its low dropout voltage characteristic supports operation with minimal input-output differential voltage, making it energy efficient in scenarios where input power is limited or variable.
Adjustable output voltage with low dropout for efficient regulation. Maximum input voltage 30 volts for versatile application use. Low quiescent current of 5 mA conserves energy. Compact 3-pin surface mount package aids circuit design.
Rated for maximum operating temperatures up to 125°C for reliability. Positive polarity design typical for regulated power supplies. Ideal for industrial, electronics manufacturing, and power management systems. Supports embedded system power regulation and battery charging circuitry.
This product is an ideal choice for engineers and technicians requiring a reliable, adjustable Voltage Regulator with superior electrical characteristics and compact form factor. Browse EnvMart for more electronics components and power management solutions from top brands like Texas Instruments.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum input voltage for this model is 30 volts.
It has a low quiescent current of 5 mA, which helps optimize power consumption.
This voltage regulator measures 10.16 mm in length, 8.64 mm in width, and 4.57 mm in height.
The LM1086IS-ADJ/NOPB is rated for a maximum operating temperature of 125°C.
It features a surface mount configuration, which facilitates easy PCB integration.
The output voltage is adjustable, allowing designers to tailor it to specific circuit requirements.
It utilizes a positive polarity design, typical for regulated power supplies.
It is designed for use in power management applications in electronics and industrial circuits, including power supplies and battery chargers.
The minimum input voltage for the LM1086IS-ADJ/NOPB is 2.6 volts.
This voltage regulator has a 3-pin configuration, which aids in its integration into circuits.
No, this model does not have automotive standard certification and is suitable for general electronics use.
The series designation for this model is LM1086.
