Wurth Elektronik Shielded Wirewound Surface Mount Inductor 1 μH ±10 % 450 mA IDC Ferrite Core 1812 WE-GF 74476601
Specifications
| Country of Origin | China |
|---|---|
| Brand | Wurth Elektronik |
| Height | 3.2mm |
| Length | 4.2mm |
| Model | 74476601 |
| Depth | 3.2mm |
| Packaging | Tape & Reel |
| Series | WE-GF |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 1μH |
| Package/Case | 1812 |
| Maximum DC Current | 450mA |
| Pin Count | 2 |
| Maximum DC Resistance | 500mΩ |
| Inductance Tolerance | ±10 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 310MHz |
| Minimum Quality Factor | 50 |
| Inductor Construction | Wirewound |
Key Features
- Constructed with a ferrite core for enhanced magnetic performance.
- Designed in an 1812 package size with dimensions 4.2mm x 3.2mm x 3.2mm.
- Features a high quality factor of 50 for efficient energy storage.
- Supports maximum operating temperature of 105°C and minimum operating temperature of -40°C.
- Shielded design reduces electromagnetic interference.
- Termination style is surface mount for easy PCB integration.
- Maximum DC resistance is 500 mΩ to minimize power loss.
- Suitable for high frequency applications up to 310 MHz self-resonant frequency.
Product Description
Wurth Elektronik 74476601 is a shielded wirewound surface mount inductor featuring a ferrite core, valued at an inductance of 1 μH with ±10 % tolerance and a maximum DC current rating of 450 mA. This 1812-sized component measures 4.2 mm in length, 3.2 mm in height, and 3.2 mm in depth with a surface mount termination style, making it ideal for compact PCB design.
Engineered for high frequency applications, it attains a minimum quality factor of 50 and a maximum self-resonant frequency of 310 MHz. Its shielded design ensures reduced electromagnetic interference, enhancing signal integrity in circuits such as HF amplifiers, oscillators, transponders, LC filter circuits, and adapter networks.
The inductor supports a broad operating temperature range from -40°C to 105°C, suitable for demanding industrial environments. Maximum DC resistance is limited to 500 mΩ, maintaining efficiency and minimizing energy loss. The wirewound construction on a ferrite core increases inductance stability and reliability.
Packaging in tape & reel format facilitates automated pick-and-place assembly processes. This product is manufactured in China under the WE-GF series specialized for high frequency choke and filtering tasks in electronic components and power connector applications.
Constructed with a ferrite core for enhanced magnetic performance. 1812 package size with compact dimensions for space-saving PCB layouts. Shielded wirewound design reduces electromagnetic interference. High quality factor ensures efficient energy storage in high frequency circuits.
Wide operating temperature range for reliability in harsh conditions. Surface mount termination style compatible with modern PCB assembly. Low DC resistance minimizes power loss. Supports frequency applications up to 310 MHz.
Available in tape & reel packaging for streamlined manufacturing. Wirewound construction offers stable inductance.
This Wurth Elektronik shielded wirewound surface mount inductor is suitable for industrial, laboratory, electronic, and commercial electronics assembly and engineering projects. Browse more components in the Surface Mount Inductor category on EnvMart to find complementary passive components and enhance your designs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 1 μH with a tolerance of ±10%.
This inductor has dimensions of 4.2 mm in length, 3.2 mm in height, and 3.2 mm in depth, conforming to the 1812 package size.
The maximum DC current rating for this unit is 450 mA.
The maximum self-resonant frequency is 310 MHz, making it suitable for high frequency applications.
It features a surface mount termination style, allowing for easy integration into PCBs.
This inductor operates within a temperature range of -40°C to 105°C.
The maximum DC resistance is 500 mΩ, which helps minimize power loss.
It is constructed with a ferrite core, which enhances its magnetic performance.
This model has a minimum quality factor of 50, ensuring efficient energy storage.
The inductor is packaged in tape & reel format, facilitating automated assembly processes.
This product is manufactured in China.
It is suitable for high frequency applications such as HF amplifiers, oscillators, and LC filter circuits.
