XP Power DC/DC Converter PCB Mount High Voltage Regulated 1W Power Supply C Series C05

XP Power C05 DC/DC Converter is a high voltage, non-isolated converter designed for integration with sensitive low-power electronic devices. Featuring a regulated output with very low noise through a quasi-sinewave oscillator, this miniature PCB mount power supply provides up to 1 W of power with output voltages of 11.5 V or 16 V DC. It supports a wide input voltage range from 11.5 V to 16 V DC, allowing stable operation over variable supply conditions.

The converter features a sealed steel case with isolated case grounding, ensuring durability and resistance to environmental stress, including immersion cleaning processes. With a maximum operating temperature of 60°C and minimum of -10°C, it caters well to industrial and laboratory environments requiring reliable voltage conversion.

This unit’s very low ripple and noise (0.004% peak-to-peak) make it ideal for noise-sensitive applications such as photomultiplier tubes, solid-state detectors, electrophoresis equipment, piezoelectric devices, capacitor charging circuits, and electron optics lenses.

With a mean time between failures (MTBF) of 2,600,000 hours, it promises exceptional reliability for continuous duty in demanding fields including industrial measurement, medical instrumentation, and scientific research.

Input voltage range from 11.5 V to 16 V DC ensures wide compatibility. Output voltage options of 11.5 V or 16 V DC support various load requirements. Compact PCB mount design measuring 35.56 mm in length and 28.19 mm in width.

Low ripple and noise at 0.004% peak-to-peak enhances output stability. High MTBF rating of 2,600,000 hours ensures long-term reliability. Operates within temperature ranges from -10°C to 60°C for versatile environments. Constructed with a sealed, steel case with isolated case ground for durability.

Ideal for use in photomultiplier tubes, piezo devices, electrophoresis, and capacitor charging applications. Certified to UL (E344664) and RoHS standards for safety and environmental compliance.

This XP Power DC/DC Converter C Series C05 is manufactured in the United States and provides a dependable solution for high-voltage DC power conversion in electronic and industrial applications. Explore more power supply solutions and electronic components on EnvMart.
