Nexperia Low Saturation Voltage PNP Transistor 5 A, 20 V, Surface Mount, 4-Pin UPAK PBSS5520X,135

Nexperia PBSS5520X,135 is a low saturation voltage PNP bipolar junction transistor designed to deliver high collector current capacity of up to 5 A and a maximum collector-emitter voltage rating of 20 V. Housed in a compact 4-pin UPAK surface mount package, it is suitable for space-limited industrial applications.

The transistor offers excellent switching performance with a maximum transition frequency of 100 MHz and minimum DC current gain (hFE) of 150, making it ideal for digital circuits and power switching uses.

With a power dissipation rating of 2.5 W and robust operation across a wide temperature range (-65°C to 150°C), this transistor ensures reliable function under harsh environmental conditions commonly found in industrial and automotive electronics.

The compact dimensions (4.6 mm length, 2.5 mm width, 1.5 mm height) and surface mount design enable efficient PCB layout and assembly processes. The product complies with RoHS standards, assuring environmentally responsible manufacturing practices.

This PNP transistor supports a maximum DC collector current of -5 A. Maximum collector-emitter voltage is rated at -20 V for safe operation. Features low saturation voltage to reduce power loss and heat generation. Maximum power dissipation capability is 2.5 W.

Transistor configuration is single with a 4-pin UPAK surface mount package. High frequency operation with a transition frequency of 100 MHz. Wide operating temperature range from -65°C to 150°C for industrial robustness.

RoHS compliant for environmental safety and regulatory compliance. This transistor series is widely used in electronic industrial equipment, power switching, automotive electronics, and digital circuits for improved efficiency and reliability.
