XP Power AH Series Isolated DC/DC Converter 800V DC Output, 1.87mA, 5V DC Input, Through Hole Mount, 1.5W Power AH08P-5
Specifications
| Country of Origin | United States |
|---|---|
| Voltage | Converters / DC-DC Converters XP Power AH DC/DC Converter, 800V dc/ 1 |
| Brand | XP Power |
| Length | 23.37mm |
| Model | AH08P-5 |
| Depth | 6.35mm |
| Gross Weight | 5.7g |
| Width | 11.43mm |
| Mount Type | Through Hole |
| Series | AH |
| Maximum Operating Temperature | 75°C |
| Minimum Operating Temperature | -25°C |
| MTBF | 1862000h |
| Number of outputs | 1 |
| Ripple and Noise | 1.2% Pk-Pk |
| Maximum Output Power | 1.5W |
| Maximum Input Voltage | 5V dc |
| Minimum Input Voltage | 0V dc |
| Output Voltage 1 | 800V dc |
| Output Current 1 | 1.87mA |
| Isolation Voltage | 500V |
Key Features
- This converter provides galvanic input to output isolation with 500V isolation voltage.
- It supports a wide operating temperature range from -25°C to 75°C.
- Designed for minimal size and weight, weighing only 5.7 grams.
- The converter features a quasi-sinewave oscillator and low output/input capacitance.
- It requires no external components and protects against short circuits with minimum 1-minute duration.
- Applications include avalanche photodiodes, capacitor charging, electrophoresis, photomultiplier tubes, and piezo devices.
- It is suitable for industrial, laboratory, and scientific use where precise high-voltage DC output is required.
Product Description
XP Power AH08P-5 isolated DC/DC converter is part of the AH series known for ultra-miniature power isolated converters converting DC to high voltage DC output. It provides an output voltage of 800V DC at 1.87mA current with an input voltage range of 0 to 5V DC and a power rating of 1.5W. The device is mounted via through-hole technology and operates between -25°C to 75°C, designed for reliable performance in demanding industrial environments.
This converter offers galvanic isolation with an isolation voltage of 500V, ensuring safe separation between input and output circuits. It incorporates a quasi-sinewave oscillator for low leakage current and low output/input capacitance, allowing stable and noise-minimized operation. The device includes a minimum one-minute short circuit protection mechanism and requires no external components, simplifying integration in custom embedded applications.
Applications for this DC/DC converter span across precision fields like avalanche photodiodes, capacitor charging circuits, electrophoresis setups, photomultiplier tube supplies, piezo devices, mass spectrometry instrumentation, and sustaining ion pumps where stable high voltage DC supply is critical.
This converter provides galvanic input to output isolation with 500V isolation voltage. It supports a wide operating temperature range from -25°C to 75°C. Designed for minimal size and weight, weighing only 5.7 grams. The converter features a quasi-sinewave oscillator and low output/input capacitance.
It requires no external components and includes short circuit protection. Ideal for scientific, industrial, laboratory, and water treatment applications.
Manufactured in the United States, this device meets the quality standards required for high reliability applications but carries no specific certifications. It is a new product from XP Power’s AH series, designed for advanced electronic designs requiring compact and efficient DC to high voltage DC conversion.
Explore more high-quality DC/DC Converters and power supply components at EnvMart to find the right solution for your industrial and scientific power needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The AH08P-5 DC/DC converter provides an output voltage of 800V DC with an output current of 1.87mA.
This model accepts an input voltage range from 0V DC to 5V DC.
The maximum output power of the AH08P-5 is 1.5W.
The converter offers an isolation voltage of 500V, ensuring safe separation between input and output circuits.
The dimensions of the AH08P-5 are 23.37mm in length, 11.43mm in width, and 6.35mm in depth.
It operates within a temperature range of -25°C to 75°C.
This model uses through-hole mounting technology.
No, it requires no external components, simplifying integration into custom applications.
The converter includes short circuit protection that can withstand a minimum duration of one minute.
It is suitable for applications such as avalanche photodiodes, capacitor charging, electrophoresis, and photomultiplier tubes.
The weight of this model is 5.7 grams.
The mean time between failures (MTBF) for this converter is 1,862,000 hours.
