SMC Pneumatic Compact Cylinder 10mm Bore, 75 mm Stroke, Double Acting Aluminium Alloy Body CXSJM10-75

SMC CXSJM10-75 Pneumatic Compact Cylinder is a precision-engineered actuator with a 10mm bore and 75mm stroke length, constructed from durable aluminium alloy. It features a double acting mechanism suitable for various pneumatic automation and fluid power applications in industrial environments.

This compact cylinder offers a double acting action type that provides force in both extension and retraction strokes, making it ideal for precise positioning and control in manufacturing, packaging, and assembly lines. Its through hole mounting type allows for easy installation and secure fitting within pneumatic systems.

The cushioning rubber bumper minimizes impact at stroke ends, reducing operational noise and mechanical wear for enhanced longevity. The cylinder can safely operate at maximum pressures up to 0.7 MPa and supports piston speeds up to 700 mm/s, suitable for rapid cycling requirements.

Designed for reliable performance in temperatures ranging from -10°C to 60°C, the unit includes a double rod for augmented stability and minimized side load effects during operation. The piston rod features an M5 metric thread standard to ensure compatibility with a range of pneumatic components and accessories.

Weighing approximately 200 grams, this lightweight compact cylinder is well-suited for diverse industrial uses including robotics, material handling, conveyor control, and automation systems within manufacturing and processing plants.

Compact 10mm bore size with 75 mm stroke length for versatile linear actuation. Double acting design for bidirectional piston movement control. Robust aluminium alloy body ensures strength and corrosion resistance. Rubber bumper cushioning reduces noise and mechanical stress.

Operates under maximum pressure of 0.7 MPa at speeds up to 700 mm/s. Through hole mount type for flexible installation options. Double rod construction enhances stability and accuracy. Suitable for operating temperatures from -10°C to 60°C.

Piston rod M5 thread with metric standard for accessory compatibility. Lightweight design with gross weight around 200 grams.

For applications requiring reliable, compact pneumatic actuation in industrial, manufacturing, laboratory, automation, and packaging contexts, the SMC CXSJM10-75 provides exceptional performance and durability. Explore related Pneumatic Cylinders and actuators in EnvMart Industrial category for comprehensive automation solutions.
