Samtec LSEM Series Straight Surface PCB Header 40 Contacts 0.8 mm Pitch 2 Row Shrouded LSEM-120-06.0-L-DV-A-N-K-TR

Free Delivery in India | Lowest Global Shipping Charges

Samtec LSEM Series Straight Surface PCB Header 40 Contacts 0.8 mm Pitch 2 Row Shrouded LSEM-120-06.0-L-DV-A-N-K-TR

Name: Samtec LSEM Series Straight Surface PCB Header 40 Contacts 0.8 mm Pitch 2 Row Shrouded LSEM-120-06.0-L-DV-A-N-K-TR
Brand: Samtec
SKU: 193358
Price: 7.79 USD
Availability: InStock



Category PCB Header Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	225, 318V ac
Brand	Samtec
Orientation	Straight
Current	1.8A
Model	LSEM-120-06.0-L-DV-A-N-K-TR
Mount Type	Surface
Housing Material	Liquid Crystal Polymer
Contact Material	Phosphor Bronze
Series	LSEM
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	0.8mm
Contact Plating	Gold
Number of Contacts	40
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Board-to-Board

Key Features

The connector features a shrouded, 2-row design ensuring secure mating.
Contacts are made of phosphor bronze with gold plating for reliable conductivity.
Housing is constructed from high-performance liquid crystal polymer.
Rated for a current of 1.8A and voltage up to 318V AC.
Termination type is solder, suitable for surface mounting applications.
Operating temperature ranges from -55°C to 125°C.
Hermaphroditic design reduces inventory requirements by allowing self-mating connectors.
Ideal for high-speed, high-density parallel and perpendicular board-to-board systems.

Product Description

Samtec LSEM-120-06.0-L-DV-A-N-K-TR is a straight surface-mounted PCB header in the LSEM Series designed for robust electronic interconnect applications. It features 40 male contacts arranged in 2 rows with a pitch of 0.8 mm, providing a compact, high-density connection solution.

The housing material is liquid crystal polymer, chosen for its excellent mechanical and thermal stability. Contact material consists of phosphor bronze with gold plating, enhancing electrical performance and corrosion resistance. The shrouded configuration ensures protection and precise alignment during mating, minimizing wear and connection failures.

This connector supports a maximum current rating of 1.8A and voltage ratings up to 318V AC, suitable for a wide range of electronics and power applications. The termination type is solder, configured for surface mounting on printed circuit boards.

Designed for operation in harsh environments, it withstands temperatures from -55°C to 125°C. Its hermaphroditic design allows self-mating, simplifying inventory and assembly logistics. The connector is ideal for high-speed data and power transmission in high-density electronic equipment.

Applications include electronic components, power connectors, and specialized PCB assemblies in industrial, commercial, and laboratory electronics fields. The slim ruggedized design and high retention contacts support reliable performance for critical electronic interconnects.

The connector has 40 contacts arranged for high-density configurations. Shrouded for reliable mechanical connection and protection. High-quality phosphor bronze contacts plated with gold for durability. Surface mount termination suitable for automated PCB assembly.

Operating temperature range supports demanding environmental conditions. For more specific industrial and electronic connector solutions, explore the wider Samtec LSEM Series connectors and related PCB Header products on EnvMart.
