TDK VLS-EX 5045 Shielded Wirewound Surface Mount Inductor with Ferrite Core 47 μH ±20% 1 A Idc VLS5045EX-470M
Specifications
| Country of Origin | India |
|---|---|
| Brand | TDK |
| Height | 4.5mm |
| Length | 5mm |
| Model | VLS5045EX-470M |
| Depth | 5mm |
| Series | VLS-EX |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 47μH |
| Standards/Approvals | RoHS |
| Package/Case | 5045 |
| Maximum DC Current | 1A |
| Pin Count | 2 |
| Maximum DC Resistance | 300mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Inductor Construction | Wirewound |
Key Features
- Magnetically shielded design reduces electromagnetic interference in power circuits.
- Wirewound construction on ferrite core ensures high current handling capability.
- Compact 5045 package measuring 5 mm length, 4.5 mm height, and 5 mm depth.
- Operates reliably in temperature range from -40°C to 105°C.
- Maximum DC resistance is limited to 300 mΩ for efficient performance.
- Surface mount termination style allows high-density PCB mounting.
- Meets RoHS compliance with moulded ferrite core construction.
- Ideal for use in TVs, game devices, set-top boxes, and audiovisual equipment.
Product Description
TDK VLS5045EX-470M shielded wirewound surface mount inductor with ferrite core offers an inductance of 47 μH ±20% tolerance and supports a maximum DC current of 1 A, making it suitable for various power circuit applications. The component is designed with a magnetically shielded construction that effectively mitigates electromagnetic interference, achieved through a ferrite magnetic material core optimized for high-density mounting.
The device comes in a compact 5045 package size measuring 5 mm in length, 4.5 mm in height, and 5 mm in depth, enabling efficient use in space-constrained PCB designs. It features a wirewound inductor construction with surface mount termination style, ensuring robust electrical performance and ease of assembly. The inductor operates reliably across a temperature range of -40°C to 105°C and exhibits a maximum DC resistance of 300 mΩ, which contributes to lowered power losses.
This moulded ferrite core inductor complies with RoHS environmental standards, ensuring it meets modern manufacturing and safety requirements. Its high current rating and magnetic shielding make it ideal for usage in a variety of electronic devices including televisions, game consoles, set-top boxes, and audiovisual equipment, where noise-free power delivery is critical.
Magnetically shielded construction reduces electromagnetic noise. Wirewound inductor built on a ferrite core for durability and performance. Compact 5045 surface mount package suitable for high-density boards. Wide operational temperature range from -40°C to 105°C for versatile applications.
Low maximum DC resistance of 300 mΩ minimizes power losses. Surface mount termination style supports automated PCB assembly. Compliant with RoHS standards for environmental safety. Designed for industrial and consumer electronics including TVs and audiovisual equipment.
This TDK Surface Mount Inductor is highly suited for industrial and commercial electronic component applications requiring reliable inductance and current handling features. Browse other high-quality passive components in the Electronics & Electricals category at EnvMart for your project requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this inductor is 47 μH with a tolerance of ±20%.
It supports a maximum DC current of 1 A.
The maximum DC resistance is limited to 300 mΩ, which helps in reducing power losses.
The dimensions of the 5045 package are 5 mm in length, 4.5 mm in height, and 5 mm in depth.
It operates reliably in a temperature range from -40°C to 105°C.
This model features a wirewound construction on a ferrite core, which ensures high current handling capability.
It has a surface mount termination style, allowing for high-density PCB mounting.
Yes, it meets RoHS compliance standards, ensuring it adheres to environmental safety requirements.
It is ideal for use in TVs, game devices, set-top boxes, and audiovisual equipment.
This inductor has a pin count of 2.
The core material of the TDK VLS5045EX-470M is ferrite.
This model belongs to the VLS-EX series.
