Relpol PCB Mount Miniature Power Relay, 12V DC Coil, 8A Switching Current, DPDT Contact Configuration RM84-2012-35-1012
Specifications
| Country of Origin | Poland |
|---|---|
| Brand | Relpol |
| Height | 15.7mm |
| Length | 29mm |
| Model | RM84-2012-35-1012 |
| Width | 12.7mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | RM84 |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | DPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 8A |
| Terminal type | Plug-In |
| Contact Resistance | 100mΩ |
| Standards/Approvals | EAC, RoHS |
| Coil Resistance | 360Ω |
| Coil Voltage | 12V dc |
| Switching DC Voltage | 24V dc |
| Switching AC Voltage | 440V |
| Coil Power | 480mW |
Key Features
- This miniature relay is designed for PCB mounting or plug-in socket installation.
- It supports a switching current of 8A with silver alloy contacts for reliable performance.
- The coil resistance is 360 ohms with a coil power consumption of 480mW.
- Operates in a temperature range from -40°C to 85°C ensuring robustness in harsh environments.
- The relay switches AC voltage up to 440V and DC voltage up to 24V with a switching power of 2kVA.
- Extremely compact dimensions with a height of 15.7mm, width of 12.7mm, and length of 29mm.
- Contact resistance is low at 100 milliohms maintaining efficient conductivity.
- Meets RoHS compliance and EAC standards, manufactured in Poland.
Product Description
Relpol RM84-2012-35-1012 PCB Power Relay is an industrial-grade miniature relay designed for PCB mounting or use in plug-in sockets. It features a 12V DC coil with a coil resistance of 360 ohms and coil power of 480 milliwatts, making it energy efficient and suitable for prolonged operation in electrical and automation applications.
This relay offers a DPDT (Double Pole Double Throw) contact configuration capable of handling switching currents up to 8 amperes. The contact material is silver alloy, ensuring excellent conductivity and durability. The contact resistance is minimal at 100 milliohms, enhancing performance in sensitive electrical circuits.
Designed to endure harsh operating conditions, it functions reliably in temperatures ranging from -40°C to 85°C. It supports switching voltages up to 440V AC and 24V DC, with a switching power rating of 2 kilo-volt-amperes (kVA), making it suitable for a variety of industrial power relay applications including electrical control systems, automation assemblies, and signal conditioning circuits.
The compact size with dimensions of 29mm length, 12.7mm width, and 15.7mm height allows integration into space-constrained PCB layouts customary in industrial and commercial electronic designs. The relay is RoHS compliant and adheres to EAC certification standards, reflecting its compliance to environmental and safety regulations.
Manufactured in Poland by Relpol, this RM84 series miniature relay is trusted for general-purpose versatility, energy efficiency, and long service life. Ideal for industrial, laboratory, manufacturing, HVAC, and electrical automation uses.
This miniature relay supports PCB or plug-in socket mounting for flexible installation. High electrical ratings including 8A switching current and 2kVA switching power. Wide operating temperature range from -40°C to 85°C for durable performance.
Low coil power of 480mW reduces energy consumption during operation. Silver alloy contacts provide reliable conductivity and corrosion resistance. Compact dimensions enable easy integration into electronic assemblies. Compliance with RoHS and EAC standards ensures safety and environmental adherence.
