XP Power Isolated DC-DC Converter 5V DC Output 800mA, 18V-36V DC Input, 4W Power, Through Hole DIP Package JCA0424S05
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | Converters / DC-DC Converters XP Power JCA DC/DC Converter, 5V dc/ 800 mA, 36V d |
| Brand | XP Power |
| Efficiency | 80% |
| Length | 25.4mm |
| Model | JCA0424S05 |
| Depth | 10mm |
| Width | 20.3mm |
| Mount Type | Through Hole |
| Series | JCA |
| Maximum Operating Temperature | 100°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| MTBF | 1000000h |
| Number of outputs | 1 |
| Maximum Output Power | 4W |
| Maximum Input Voltage | 36V dc |
| Minimum Input Voltage | 18V |
| Number of Pins | 24 |
| Output Voltage 1 | 5V dc |
| Output Current 1 | 800mA |
| Isolation Voltage | 1.5kV dc |
| Input Ratio | 2:1 |
| Input Ratio2 | 1 |
Key Features
- Features a through-hole DIP package for easy PCB mounting.
- Offers wide operating temperature range from -40°C to 100°C for reliable performance.
- Isolation voltage rated at 1.5kV DC for electrical safety.
- High MTBF of 1,000,000 hours ensures long-term durability.
- Compact dimensions of 25.4mm length, 20.3mm width, and 10mm depth.
- Efficiency rating of 80% optimizes power conversion.
- Single output design with 24 pins for standard integration.
- Manufactured in Taiwan, Province Of China with robust quality controls.
Product Description
XP Power JCA0424S05 is a high-reliability isolated DC-DC converter designed for stable power supply applications in electronics and industrial environments. This converter delivers a regulated 5V DC output at up to 800mA from a wide input voltage range of 18V to 36V DC, providing 4 watts of power in a compact through-hole DIP package.
Equipped with 24 pins arranged in a 2:1 input ratio configuration, the JCA0424S05 offers a versatile and easy-to-integrate solution for engineers requiring isolated power in compact spaces. The unit's compact dimensions (25.4mm L x 20.3mm W x 10mm D) allow for dense PCB layouts, while its high mean time between failures (MTBF) of 1,000,000 hours ensures dependable long-term operation.
The converter is rated for operating temperatures from -40°C to 100°C, enabling use in harsh industrial, laboratory, and commercial environments. It features an isolation voltage of 1.5kV DC, which safeguards sensitive circuits from voltage spikes and noise, enhancing overall system reliability and safety.
With an efficiency of 80%, this converter minimizes heat generation and power loss, contributing to energy-efficient system design. This product does not carry any specific approvals or certifications but adheres to quality manufacturing standards by XP Power, a trusted global brand in power solutions.
Applications include industrial automation, embedded systems power supply, telecommunications, instrumentation, and other electronics requiring isolated voltage conversion. The product is supplied in tubes, ready for incorporation into automated production lines, improving manufacturing efficiency.
Features a through-hole DIP package for easy PCB mounting. Input voltage ratio of 2:1 supports flexible power supply design. Offers wide operating temperature range from -40°C to 100°C for reliable performance. Isolation voltage rated at 1.5kV DC for electrical safety.
High MTBF of 1,000,000 hours ensures long-term durability. Compact dimensions of 25.4mm length, 20.3mm width, and 10mm depth. Efficiency rating of 80% optimizes power conversion. Single output design with 24 pins for standard integration.
Manufactured in Taiwan, Province Of China with robust quality controls. Ideal for industrial, electronic component power supply, and embedded system applications. Explore more DC/DC Converters from XP Power to find tailored solutions for your electronic power needs at EnvMart, your trusted industrial and electronics supply partner.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model provides a regulated output voltage of 5V DC with a maximum output current of 800mA.
The input voltage range for this unit is from 18V to 36V DC.
It has an efficiency rating of 80%, optimizing power conversion and minimizing heat generation.
The dimensions of this model are 25.4mm in length, 20.3mm in width, and 10mm in depth.
The isolation voltage is rated at 1.5kV DC, providing electrical safety for sensitive circuits.
This unit can operate at temperatures up to 100°C, making it suitable for harsh environments.
This converter features 24 pins arranged in a configuration suitable for standard integration.
The MTBF for this model is rated at 1,000,000 hours, indicating long-term reliability.
It utilizes a through-hole DIP package for easy PCB mounting.
This model is suitable for applications in industrial automation, embedded systems, telecommunications, and instrumentation.
The minimum operating temperature for this unit is -40°C, allowing it to perform in cold environments.
The input ratio for this model is 2:1, supporting flexible power supply designs.
