Wurth Elektronik WR-BTB Series Vertical Surface PCB Header 80 Contacts 0.8 mm Pitch 1 Row Shrouded 658857603080
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 50V |
| Brand | Wurth Elektronik |
| Orientation | Vertical |
| Current | 500mA |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Copper Alloy |
| Series | WR-BTB |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 0.8mm |
| Contact Plating | Gold |
| Number of Contacts | 80 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Board-to-Board |
| Withstanding Voltage | 500 V (AC) |
| Insulator Material | LCP |
Key Features
- Constructed with liquid crystal polymer housing for durability.
- Copper alloy contacts plated with gold ensure reliable conductivity.
- Supports a maximum operating temperature range of -55°C to 85°C.
- Designed for 50 V and 500 mA current rating.
- Vertical orientation suitable for vertical SMT mounting.
- Shrouded design enhances contact protection and alignment.
- Termination type is solder for secure mounting.
- Single row configuration with a pitch of 0.8 mm.
Product Description
Wurth Elektronik 658857603080 WR-BTB Series Vertical Surface PCB Header features 80 gold-plated copper alloy contacts arranged in a single row with 0.8 mm pitch. The product is housed in liquid crystal polymer (LCP), providing durability and thermal resistance. It is designed for vertical SMT mounting on printed circuit boards and provides reliable board-to-board connection for electronic devices.
Operating temperature ranges from -55°C to 85°C, allowing usage in diverse environmental conditions. Its electrical specifications include a voltage rating of 50 V and a maximum current rating of 500 mA, suitable for low-power applications.
The header is shrouded to ensure enhanced protection and precise mating alignment during installation. Termination is via soldering, providing a secure mechanical and electrical connection to the PCB.
This component is ideal for use in electronics manufacturing, industrial automation, communication equipment, and embedded systems that require reliable and compact interconnection solutions.
Durable LCP housing withstanding wide temperature ranges. High-quality gold-plated copper alloy contacts for excellent conductivity. Shrouded connector system for secure and accurate board connections. Vertical SMT mounting suitable for modern PCB layouts.
Rated for 50 V and 500 mA, ideal for low-current applications. Single row with 0.8 mm pitch ensures dense packing. Suitable for industrial and electronic equipment applications. Choose Wurth Elektronik’s WR-BTB Series for high-reliability PCB Header solutions. Browse more PCB Headers at EnvMart for your electronics assembly needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The voltage rating of this PCB header is 50 V.
It has a maximum current rating of 500 mA.
The pitch of the contacts is 0.8 mm.
The housing is constructed from liquid crystal polymer (LCP).
This model features 80 contacts arranged in a single row.
It operates within a temperature range of -55°C to 85°C.
The termination type is solder, allowing for secure mounting.
Yes, this model features a shrouded design for enhanced contact protection and alignment.
It is designed for vertical orientation suitable for vertical SMT mounting.
It provides a board-to-board connector system.
The contacts are made of copper alloy and are plated with gold for reliable conductivity.
The country of origin for this product is China.
