Wurth Elektronik WR-PHD Series Straight Surface PCB Header 16 Contacts 2 mm Pitch 2 Row Unshrouded 62101621921
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 200V |
| Brand | Wurth Elektronik |
| Orientation | Straight |
| Current | 2A |
| Mount Type | Surface |
| Housing Material | Polyamide |
| Contact Material | Copper Alloy |
| Series | WR-PHD |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 2mm |
| Contact Plating | Gold |
| Number of Contacts | 16 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
Key Features
- Features a straight surface mount design compatible with SMT technology.
- Constructed with polyamide housing for durability and stability.
- Contact material is copper alloy with gold plating for reliable conductivity and corrosion resistance.
- Supports a current rating of 2 A and a voltage rating of 200 V.
- Operating temperature range from -40°C to 105°C for versatile applications.
- Designed with male contact gender and solder termination type.
- Unshrouded connector system, allowing easy mating with corresponding sockets.
- Offers high contact reliability with a maximum contact resistance of 20 mΩ.
Product Description
Wurth Elektronik 62101621921 WR-PHD Series PCB Header is a 2.00 mm pitch straight surface mount connector featuring 16 male contacts arranged in 2 rows. This unshrouded dual-row pin header is constructed with high-quality polyamide housing combined with copper alloy contacts plated in gold to ensure excellent electrical conductivity and durability in demanding electronic applications.
This header supports a current rating of 2 A and voltage rating of 200 V, operating reliably across a temperature range of -40°C to +105°C. Its solder termination type facilitates secure mounting on printed circuit boards with surface mount technology.
The connector system is designed for board-to-board connections and is suitable for use in various industrial applications, including electronic component assembly and manufacturing.
The WR-PHD Series header provides high reliability withstanding voltage up to 500 V AC and low contact resistance around 20 mΩ, ensuring stable signal transmission over extensive mating cycles (up to 500 cycles). The male contacts are unshrouded allowing flexible mating options with compatible connectors.
Manufactured in China, this product is RoHS compliant and UL approved under certification E323964, guaranteeing adherence to international quality and environmental standards. Features a straight surface mount design for precision PCB assembly.
Polyamide housing offers mechanical and thermal stability. Copper alloy contacts with gold plating ensure excellent conductivity and corrosion resistance. Current rating of 2 A and voltage rating of 200 V suit diverse electrical requirements.
Support for -40°C to 105°C operating temperature range enhances durability. Solder termination provides secure and efficient PCB mounting. Unshrouded male contacts facilitate versatile connector mating. Meets RoHS and UL E323964 certification for quality assurance.
This Wurth Elektronik PCB Header is ideal for industrial electronic assemblies requiring reliable board-to-board connectivity with durable construction and safety certifications. Explore the Electronics Components category on EnvMart for compatible PCB Headers and connectors from trusted brands.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a voltage rating of 200 V, making it suitable for various electrical applications.
It supports a current rating of 2 A, allowing it to handle a range of electrical loads.
The operating temperature range is from -40°C to 105°C, enabling its use in diverse environments.
The contacts are made of copper alloy and are plated with gold to ensure reliable conductivity and corrosion resistance.
This model features 16 male contacts arranged in 2 rows, designed for efficient board-to-board connections.
It utilizes a solder termination type, which provides secure mounting on printed circuit boards.
Yes, this product is RoHS compliant, ensuring it meets environmental standards for hazardous substances.
The maximum contact resistance is around 20 mΩ, which contributes to stable signal transmission.
The pitch size of the contacts in this header is 2 mm, suitable for surface mount technology.
This PCB header is manufactured in China, adhering to international quality standards.
It features a board-to-board connector system, allowing for versatile mating options with compatible connectors.
This model has a straight orientation, which is designed for precision PCB assembly.
