Nexperia 4.7 V Zener Diode Single 500 mW 5 % Surface Mount 2-Pin SOD-80 BZV55-C4V7,115

Free Delivery in India | Lowest Global Shipping Charges

Nexperia 4.7 V Zener Diode Single 500 mW 5 % Surface Mount 2-Pin SOD-80 BZV55-C4V7,115

Name: Nexperia 4.7 V Zener Diode Single 500 mW 5 % Surface Mount 2-Pin SOD-80 BZV55-C4V7,115
Brand: Nexperia
SKU: 189653
Price: 0.04 USD
Availability: InStock



Category Zener Diodes Brand Nexperia Condition New

Specifications

Country of Origin	China
Brand	Nexperia
Height	1.6mm
Length	3.7mm
Model	BZV55-C4V7,115
Mount Type	Surface
Series	BZV55
Maximum Operating Temperature	200°C
Package Type	SOD-80
Minimum Operating Temperature	-65°C
Pin Count	2
Number of Elements per Chip	1
Maximum Power Dissipation Pd	500mW
Diode Configuration	Single
Test Current It	5mA
Maximum Reverse Leakage Current	3μA
Nominal Zener Voltage Vz	4.7V
Zener Type	Voltage Regulator
Maximum Zener Impedance	80Ω
Typical Voltage Temperature Coefficient	-1.4mV/°C

Key Features

Nominal Zener voltage is 4.7 volts with ±5% tolerance.
Supports maximum power dissipation of 500 milliwatts for reliable operation.
Surface mount package type SOD-80 with 2-pin configuration for PCB mounting.
Maximum operating temperature up to 200°C allowing use in high temperature environments.
Low maximum reverse leakage current of 3 microamperes ensuring efficiency.
Small dimensions with height 1.6 mm and length 3.7 mm suitable for compact designs.
Typical voltage temperature coefficient of -1.4 mV/°C for stable voltage regulation.
Test current rating at 5 mA to verify performance parameters.

Product Description

Nexperia BZV55-C4V7,115 Zener Diode is a high-quality discrete semiconductor component designed for voltage regulation applications in electronic circuits. Featuring a nominal zener voltage of 4.7 V with a tight 5% tolerance, this diode ensures stable voltage reference under varying electrical conditions.

The single element diode is housed in a surface mount SOD-80 package with 2 pins, facilitating easy placement on printed circuit boards for industrial and commercial electronics manufacturing. With a maximum power dissipation of 500 mW and the ability to operate continuously at temperatures up to 200°C, it is well-suited for demanding environments including automotive electronics, power supplies, and communication devices.

This diode's maximum reverse leakage current is limited to 3 microamperes, which contributes to low power loss and high efficiency in voltage regulation tasks. The compact physical dimensions of 1.6 mm height and 3.7 mm length allow integration in space-constrained assemblies.

Nexperia's BZV55 series Zener Diodes, including the BZV55-C4V7,115 model, provide reliable voltage clamp and voltage reference functions critical for protecting circuits against voltage surges and maintaining stable operation. The typical voltage temperature coefficient of -1.4 mV/°C assists in maintaining voltage stability across a range of operating temperatures.

Nominal Zener voltage is 4.7 volts with ±5% tolerance. Maximum power dissipation rated at 500 mW for continuous use. Surface mount SOD-80 package with 2-pin layout for easy PCB mounting. Operating temperature range from -65°C to 200°C for robustness.

Low maximum reverse leakage current of 3 microamperes. Height of 1.6 mm and length of 3.7 mm supports compact circuit designs. Test current of 5 mA verifies electrical characteristics. Typical voltage temperature coefficient of -1.4 mV/°C aids in voltage stability.

This component is suitable for industrial, automotive, manufacturing, communication, and consumer electronics applications requiring precise voltage regulation and protection circuitry.
